Attributes
| Key | Value |
|---|---|
| Color | Black |
| Connection Material | Copper Alloy |
| Connector Type | Receptacle |
| Contact Finish | Gold Plated |
| Contact Plating Thickness | 0.76 ?m |
| Contact Type | Socket |
| Current Rating | 0.75 A |
| Flammability Rating | UL 94 V-0 |
| For Use With | Printed Circuit Board |
| Height | 0.846 in |
| Hole Center to Center | 1.9 mm |
| Hole Dia. | 0.015 in |
| Item | Connector |
| Length | 19 mm |
| Material | Liquid Crystal Polymer |
| Max. Temp. | 85?C |
| Max. Voltage | 30V AC/DC |
| Number of Contacts | 150 |
| Number of Rows | 15 |
| Package Quantity | 1 |
| Standards | CSA Certified; UL E28476; UL Recognized |
| Terminal Finish | Matte Tin Plated |
| Terminal Type | Through Hole - Press-Fit |
| Width | 1.272 in |
