| Application | Signal |
| Color | Black |
| Connection Material | Phosphor Bronze |
| Connector Terminates To | Printed Circuit Board |
| Connector Type | Header |
| Contact Finish | Gold Flash over Palladium Nickel; Gold Plated |
| Contact Plating Thickness | 0.76 ?m |
| Contact Type | Pin |
| Current Rating | 1 A |
| Features | With Ejection Latches |
| Flammability Rating | UL 94 V-0 |
| Height | 13.94 mm |
| Hole Center to Center | 2.54 mm |
| Item | Connector |
| Length | 44.7 mm |
| Material | Glass-Filled Nylon/Polyester |
| Max. Temp. | 105?C |
| Max. Voltage | 250V AC |
| Number of Contacts | 20 |
| Number of Rows | 2 |
| Package Quantity | 1 |
| Terminal Finish | Tin Plated |
| Terminal Type | Through Hole |
