1658610-4

B00LQPU8OQ

TE CONNECTIVITY / AMP 1658610-4 D SUB CONNECTOR, STANDARD, 9POS, RCPT (100 pieces)

TE CONNECTIVITY / AMP 1658610-4 D SUB CONNECTOR, STANDARD, 9POS, RCPT (100 pieces)zoom

Attributes

Key Value
Agency ApprovalsUL Recognized ; UL List.
AngleStraight
ApplicationCommercial
Backset Spacing-
Base Product Number1658610
Cable Insulation Diamet..81 ? .97?mm?[?.032 ? ..
CategoryConnectors, Interconnec.
Centerline (Pitch)2.77?mm?[?.0545?in?]
Circuit ApplicationSignal
ColorBlack
ConnectorWire & Cable
Connector Mounting TypeCable Mount (Free-Hangi.
Connector StyleD-Sub, Receptacle
Connector SystemCable-to-Cable
Connector TypeReceptacle, Female Sock.
Contact Base MaterialPhosphor Bronze
Contact Current Rating .1.25
Contact FinishGold
Contact Finish Thickness30.0?in (0.76?m)
Contact Form-
Contact MaterialPhosphor Bronze
Contact PlatingGold
Contact Size20
Contact TypeSignal
Contact Underplating Ma.Nickel
Country of Origin (subj.China
Current Rating1.25 A
Current Rating (Amps)1.25A
DescriptionCONN D-SUB RCPT 9POS IDC
Detailed Description9 Position D-Sub Recept.
Dielectric MaterialThermoplastic
Digi-Key Part NumberAFL09B-ND
EnclosureWithout
FeaturesFeed Through
Flange FeatureHousing/Shell (4-40)
Housing MaterialThermoplastic
Ingress Protection-
Insert MaterialBrass
Insulation Diameter0.032-0.038 "
ManufacturerTE Connectivity AMP Con.
Manufacturer Product Nu.1658610-4
Material Flammability R.UL94 V-0
Mating Connector LockWith
Mating Connector Lock T.Threaded Insert, 4-40 U.
Mating HardwareThreaded Inserts
MfrTE Connectivity AMP Con.
Mounting TypeFree Hanging (In-Line)
Number of Contacts9
Number of Positions9
Number of Rows2
Operating Temperature-55?C ~ 105?C
Operating Temperature R.-55 ? 105??C?[?-67 ? 22.
PackageBulk
PCB Contact Termination.Tin
PCB Mount Retention TypeNone
PreloadedYes
Primary TypeD-Ribbon
Product StatusObsolete
SealableNo
SeriesHDF-20 Series, AMPLIMIT.
Shell MaterialFront Metal Shell
Shell Material, FinishSteel, Tin Plated
Shell Size1
Shell Size, Connector L.1 (DE, E)
Shell TypeFront Metal Shell
ShieldedYes
Solid Wire Size28 ? 26, .1 ? .13
Special FeaturesStrain Relief
StandardsUL94 V-0
TerminationIDC, Ribbon Cable, IDC/.
Termination Method to W.Insulation Displacement.
TypeCable Socket
Voltage Rating250 V, -
Wire Gauge26-28 AWG, Stranded or .
Wire Size28 ? 26, .08 ? .15, 26-.
Wire/Cable TypeRibbon Cable

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Freelance Electronics1658610-41.694712TE Connectivity1.6947 @ 2
WaldomTE CONNECTIVITY AMP BRAND 1658610-44.454012854TE CONNECTIVITY/AMP BRAND4.45 @ 40
Avnet1658610-44.53840186TE Connectivity4.538 @ 40
Onlinecomponents.com1658610-45.8211724TE Connectivity / AMP Brand5.82 @ 2
Future Electronics44562166.5521128TE Connectivity6.552 @ 2
thumbzoomNewark42K66507.036002AMP - TE CONNECTIVITY7.03 @ 600
TE Connectivity1658610-47.6534311443TE Connectivity (TE)7.65343 @ 2
thumbzoomZoroG7009794439.0402Te Connectivity9.0 @ 40
us.rs-online.com700430299.85187TE Connectivity9.85 @ 2
AmazonTPB00OVEIZHG11.28122T-E Connectivity11.28 @ 2
RS Delivers680-7762P11.3761387TE Connectivity11.376 @ 2
thumbzoomTME1658610-411.417TE Connectivity11.4 @ 2
thumbzoomDigi-Key82535412.3121139TE Connectivity AMP Connectors12.312 @ 2
