TE CONNECTIVITY / AMP 1-5747871-3 D SUB CONNECTOR, STANDARD, 9POS, PLUG (10 pieces)

TE CONNECTIVITY / AMP 1-5747871-3 D SUB CONNECTOR, STANDARD, 9POS, PLUG (10 pieces)zoom

Attributes

Key Value
Alternate Part No.571-1-5747871-3
AngleStraight
ApplicationSignal
Approved StandardsUL E28476
Backset Spacing-
Base Product Number5747871
BrandTE Connectivity / AMP
CategoryConnectors, Interconnec.
Centerline (Pitch)2.74?mm?[?.108?in?]
Circuit ApplicationSignal
ColorBlack
CommentPlugs are preloaded wit.
Connection MaterialBrass
ConnectorPrinted Circuit Board
Connector Mounting TypeBoard Mount
Connector StylePlug, D-Sub
Connector SystemBoard-to-Board
Connector Terminates ToPrinted Circuit Board
Connector TypePlug, Plug, Male Pins
Contact Base MaterialBrass
Contact Current Rating .6
Contact FinishGold Flash, Gold
Contact Finish ThicknessFlash
Contact Form-
Contact MaterialBrass
Contact Mating Area Pla.Gold Flash
Contact PlatingGold Flash, Gold
Contact ShapeRound
Contact TypeSignal
Contact Underplating Ma.Nickel
Current Rating6 A
Current Rating (Amps)6A
DescriptionCONN D-SUB PLUG 9POS VE.
Detailed Description9 Position D-Sub Plug, .
Dielectric MaterialThermoplastic
Digi-Key Part NumberA34089-ND
FeaturesWith Grounding Indents,.
Female Screwlock Materi.Zinc
FinishTin Plated
Flammability RatingUL 94 V-0
Flange FeatureMating Side, Female Scr.
GenderMale
GroundedYes
Grounding ClipsWithout
Grounding IndentsWith
Grounding StrapsWithout
Hole Center to Center2.74 mm
Housing ColorBlack
Housing MaterialThermoplastic
Ingress Protection-
ItemConnector
ManufacturerTE Connectivity AMP Con.
Manufacturer Part No.1-5747871-3
Manufacturer Product Nu.1-5747871-3
Manufacturer Standard L.4 Weeks
MaterialThermoplastic
Material Flammability R.UL94 V-0
Mating Connector LockWith
Mating Connector Lock T.Female Screwlocks, Fixed
Max. Temp.105?C
MfrTE Connectivity AMP Con.
Mounting Hole Diameter3.05?mm?[?.12?in?]
Mounting TypeThrough Hole
Number of Contacts9
Number of Positions9
Number of Rows2
Operating Temperature-55?C ~ 105?C
Operating Temperature R.-55 ? 105??C?[?-67 ? 22.
PackageTube
Package Quantity1
Packaging MethodTube
Packaging Quantity17
Panel Mount FeatureWithout
PCB Contact Termination.Tin
PCB Mount OrientationVertical
PCB Mount RetentionWith
PCB Mount Retention TypeMounting Hole
PCB Mounting StyleThrough Hole
PCB Thickness (Recommen.1.57 ? 2.36?mm?[?.062 ?.
PlasticNo
Post Size.66?mm?[?.026?in?]
PreloadedYes
Primary TypeD-Sub
Product CategoryD-Sub Standard Connecto.
Product StatusActive
Product TypeConnector
ProfileStandard
Row-to-Row Spacing.112 in, 2.84 mm
SealableNo
SeriesHD-20 Series, AMPLIMITE.
Shell MaterialSteel, Front Metal Shell
Shell Material, FinishSteel, Tin Plated
Shell PlatingTin
Shell Plating MaterialTin
Shell Size1
Shell Size, Connector L.1 (DE, E)
Shell TypeFront Metal Shell
StandardsUL94 V-0, UL E28476
Terminal FinishTin Plated
TerminationSolder, Through Hole
Termination Post Length3.18?mm?[?.125?in?]
Termination StyleThrough Hole
TypePCB Plug
UL Flammability RatingUL 94V-0
Voltage Rating125V
Wire Gauge-
Wire Size20 AWG

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Onlinecomponents.com1-5747871-33.0913088TE Connectivity / AMP Brand2.93 @ 544
WaldomTE CONNECTIVITY AMP BRAND 1-5747871-33.3434500TE CONNECTIVITY/AMP BRAND3.34 @ 500
Avnet1-5747871-34.00811712TE Connectivity4.008 @ 500
TE Connectivity1-5747871-34.0582111392TE Connectivity (TE)4.05821 @ 500
thumbzoomNewark42K65474.511071500AMP - TE CONNECTIVITY4.51 @ 1071
thumbzoomDigi-Key11238654.861813497TE Connectivity AMP Connectors4.8618 @ 500
us.rs-online.com700855105.8111021TE Connectivity5.81 @ 500
RS Delivers782-60766.1561500TE Connectivity6.156 @ 500
thumbzoomswatee.com1-5747871-37.211500TE Connectivity7.21 @ 500
thumbzoomZoroG50104032890.951500Te Connectivity90.95 @ 500
