mpn:
brand:
manufacturer:
MPN:
Preferred Price:
5.37
Price:
5.37
Min Simple Price:
0.438
Absolute Min Price:
4.19
Min Price:
4.19
qty:
1
simpleSku:
NjI5OA:::2-84533-0
sku:
NjI5OA::AW:2-84533-0@x5
condition:
11
seller:
Future Electronics
amzMan:
te connectivity / amp
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Accepts Flex Cable Thickness | .3?mm?[?.012?in?] |
| Actuator Color, Actuator Material, Contact Finish Thickness, Features, Housing Color, Locking Feature, Material Flammability Rating, Mating Cycles, Series | - |
| Base Product Number | 84533 |
| Cable End Type | Tapered |
| Centerline (Pitch) | 1.25?mm?[?.049?in?] |
| Circuit Application | Signal |
| Connector | Flexible Printed Circuit (FPC) |
| Connector Height | 4.8?mm?[?.189?in?] |
| Connector Mounting Type | Board Mount |
| Connector System | Flex-to-Board |
| Connector Width | 8.8?mm?[?.346?in?] |
| Connector/Contact Type | Contacts, Top |
| Contact Base Material, Contact Material | Phosphor Bronze |
| Contact Current Rating (Max), Number of Rows | 1 |
| Contact Finish, Contact Mating Area Plating Material, PCB Contact Termination Area Plating Material | Tin |
| Contact Mating Area Plating Material Finish, PCB Contact Termination Area Plating Material Finish | Bright |
| Contact Mating Area Plating Material Thickness | .8??m?[?31.49??in?] |
| Contact Mating Location | Top |
| Contact Type | Socket |
| Current Rating (Amps) | 1A |
| FFC, FCB Thickness | 0.30mm |
| Flat Flex Type | FFC |
| Height Above Board | 0.189" (4.80mm) |
| Housing Color | White |
| Housing Material | Polybutylene Terephthalate (PBT), Glass Filled, PBT GF |
| Insertion Force Type | Non-ZIF |
| Mating Alignment, PCB Mount Alignment, PCB Mount Retention | With |
| Mfr | TE Connectivity AMP Connectors |
| Mounting Type | Through Hole, Right Angle |
| Number of Positions | 20 |
| Operating Temperature | -40?C ~ 85?C |
| Operating Temperature Range | -40 ? 85??C?[?-40 ? 185??F?] |
| Package, Packaging Method | Tray |
| Packaging Quantity | 110 |
| PCB Connector Assembly Type | PCB Mount Receptacle |
| PCB Mount Orientation | Right Angle |
| PCB Mount Retention Type | Kinked Solder Tails |
| PCB Thickness (Recommended) | 1.6?mm?[?.063?in?] |
| Pitch | 0.049" (1.25mm) |
| Product Status | Active |
| Sealable | No |
| Termination | Kinked Pin |
| Termination Method to Printed Circuit Board | Through Hole |
| Termination Post | 3.2?mm?[?.126?in?] |
| Voltage Rating | 50V |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Future Electronics | 1884949 | 0.438 | 3664.308 | 20900 | 10 | TE Connectivity | 0.438 @ Qty: 20900+ | |||
| TE Connectivity | 2-84533-0 | 0.5764 | 3.68896 | 1 | 67167 | TE Connectivity (TE) | 0.5764 @ Qty: 10+ | |||
 | Newark | 17R8695 | 0.631 | 5278.946 | 20900 | 10 | AMP - TE CONNECTIVITY | 0.631 @ Qty: 20900+ | ||
| Digi-Key | 1893441 | 0.903 | 5.7792 | 1 | 10 | TE Connectivity AMP Connectors | 0.903 @ Qty: 10+ | |||
| AmazonSC | B00DKYJELO | 1.12 | 7.168 | 1 | 10 | TE Connectivity | 1.12 @ Qty: 10+ | |||
| Onlinecomponents.com | 2-84533-0 | 1.24 | 7.936 | 1 | 472 | TE Connectivity / AMP Brand | 1.24 @ Qty: 10+ |
