mpn:
manufacturer:
MPN:
Preferred Price:
5.74
Price:
5.74
Min Simple Price:
2.386
Absolute Min Price:
4.45
Min Price:
4.45
qty:
39
simpleSku:
Tk3NDI:::528-AG11D-ES
sku:
Tk3NDI::R2:528-AG11D-ES@y0
condition:
11
seller:
iodParts
amzMan:
te connectivity / buchanan brand
HazMat:
False
DropShip:
False
Attributes
| Key | Value |
|---|---|
| Angle | Straight |
| Base Product Number | 1437536 |
| Body Material | Polyester |
| Categories | Connectors, Interconnects |
| Category | Switches |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin-Lead |
| Contact Finish Thickness - Mating | 25.0?in (0.63?m) |
| Contact Finish Thickness - Post | - |
| Contact Material | Beryllium Copper |
| Contact Material - Mating | Copper Alloy |
| Contact Material - Post | Copper Alloy |
| Contact Plating | Gold |
| Contact Resistance | 10mOhm |
| Country of Origin (subject to change) | Switzerland |
| Current Rating (Amps) | 3A |
| Description | 528-AG11D-ES=SOCKET ASSEMBLY |
| Detailed Description | Toggle Switch |
| Dielectric Material | Polyester |
| Digi-Key Part Number | 2266-5-1437536-6-ND |
| Features | Closed Frame |
| Frame Type | Closed |
| Lead Free Status / RoHS Status | Contains lead / RoHS non-compliant |
| Manufacturer | TE Connectivity AMP Connectors |
| Manufacturer Part Number | 528-AG11D-ES |
| Manufacturer Product Number | 5-1437536-6 |
| Manufacturer Standard Lead Time | 9 Weeks |
| Material Flammability Rating | UL94 V-0 |
| Mfr | TE Connectivity AMP Connectors |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| Mounting Type | Through Hole |
| Number of Contacts | 28 |
| Number of Positions or Pins (Grid) | 28 (2 x 14) |
| Operating Temperature | -55?C ~ 105?C |
| Package | Tube |
| Packaging | Tube |
| Pin Spacing | 0.1" (2.54mm) |
| Pitch - Mating | 0.100" (2.54mm) |
| Primary Type | DIP |
| Product Status | Active |
| Row Spacing | 0.3" (7.6mm) |
| Series | 500 Series, * |
| Termination | Through Hole |
All Prices
| Img | Seller | Supplier SKU | Requested Price | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| iodParts | 528-AG11D-ES | 2.386 | 165.5884 | 136 | 867 | TE Connectivity AMP Connectors | 2.386 @ Qty: 136+ | |||
| us.rs-online.com | 70087115 | 2.52 | 466.2 | 425 | 25 | TE Connectivity | 2.52 @ Qty: 425+ | |||
 | Component Electronics | 421B-28-15AN | 3.08 | 47.432 | 1 | 25 | Tyco Electronics | 3.08 @ Qty: 25+ | ||
| Hotenda | H1488441 | 3.104 | 47.8016 | 1 | 25 | TE Connectivity AMP Connectors | 3.104 @ Qty: 25+ | |||
 | Digi-Key | 14731188 | 3.72 | 81.096 | 17 | 25 | TE Connectivity AMP Connectors | 3.72 @ Qty: 25+ | ||
 | Zoro | G301044199 | 3.91 | 404.294 | 221 | 25 | Te Connectivity | 3.91 @ Qty: 221+ | ||
| Onlinecomponents.com | 5-1437536-6 | 4.09 | 59.906 | 1 | 25 | TE Connectivity / AMP Brand | 3.89 @ Qty: 26+ |
