Attributes
| Key ^ | Value |
|---|---|
| Accepts Wire Insulation Diameter Range | 2.1 ? 3.3?mm?[?.082 ? .13?in?] |
| Alternate Part No. | 571-174777-1 |
| Barrel Type | Open |
| Base Product Number | 174777 |
| Brand | TE Connectivity / AMP |
| Category | Connectors, Interconnects |
| Color, Features | - |
| Comment | Air-feed Applicator should be used. |
| Connection Capacity | Single |
| Contact Base Material, Contact Material, Material | Brass |
| Contact Finish, Contact Plating | Tin |
| Country of Origin (subject to change) | Korea, Republic of |
| Crimp Type | F-Crimp |
| Extraction Force | .7 ? 10.2, 7 ? 100 |
| Fully Insulated, Insulated, Sealable, Wire Stop | No |
| Gender | Female |
| Insertion Force | Low |
| Insulation | Non-Insulated |
| Insulation Diameter | 0.080" ~ 0.122" (2.03mm ~ 3.10mm) |
| Length - Overall | 0.677" (17.20mm) |
| Manufacturer | TE Connectivity |
| Manufacturer Part No. | 174777-1 |
| Mating Retention Type | Dimple |
| Mating Tab Thickness | .51?mm?[?.02?in?] |
| Mating Tab Width | 2.8?mm?[?.11?in?] |
| Mfr | TE Connectivity AMP Connectors |
| Mounting Type | Free Hanging (In-Line) |
| Operating Temperature Range | -40 ? 110??C?[?-40 ? 230??F?] |
| Overall Length | 17.2?mm?[?.68?in?] |
| Package | Tape & Reel (TR) |
| Packaging | Reel |
| Packaging Method | Strip/Reel |
| Packaging Quantity | 8000 |
| Plating Material | Pre-Tin |
| Product | Contacts |
| Product Category | Terminals |
| Product Status | Active |
| Receptacle Terminal Stock Thickness | .25?mm?[?.01?in?] |
| Series | Mark II |
| Tab Length | 0.236" (6.00mm) |
| Tab Thickness | 0.020" (0.51mm) |
| Tab Width | 0.110" (2.79mm) |
| Terminal Orientation | Straight |
| Terminal Type | Standard |
| Terminal, Terminal Type, Type | Receptacle |
| Terminates To | Wire & Cable |
| Termination | Crimp |
| UL Rating | Recognized |
| Wire Gauge | 16-20 AWG, 20-16 |
| Wire Insulation Support | With |
| Wire Size | 20 ? 16, .51 ? 1.31 |
| Wire/Cable Type | Regular Wire |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Waldom | TE CONNECTIVITY AMP BRAND 174777-1 | 0.05 | 160.03 | 8000 | 290000 | TE CONNECTIVITY/AMP BRAND | 0.05 @ Qty: 8000+ | |||
| Onlinecomponents.com | 174777-1 | 0.053 | 0.053 | 1 | 114110 | TE Connectivity / AMP Brand | 0.053 @ Qty: 1+ | |||
 | NEP Electronics | 174777-1 | 0.0685 | 219.2411 | 8000 | 292000 | TE Connectivity | 0.0685 @ Qty: 8000+ | ||
| Newark | 76AC1980 | 0.073 | 233.6438 | 8000 | 282000 | AMP - TE CONNECTIVITY | 0.073 @ Qty: 8000+ | |||
 | Zoro | G701009316 | 0.08 | 256.048 | 8000 | 1250 | Te Connectivity | 0.08 @ Qty: 8000+ | ||
| TE Connectivity | 174777-1 | 0.1411 | 0.1411 | 1 | 21000 | TE Connectivity (TE) | 0.1411 @ Qty: 1+ | |||
 | swatee.com | 174777-1 | 0.146 | 0.146 | 1 | 16639 | TE Connectivity | 0.146 @ Qty: 1+ | ||
| Hotenda | H1645697 | 0.15 | 0.15 | 1 | 1933 | TE Connectivity AMP Connectors | 0.15 @ Qty: 1+ | |||
| Digi-Key | 2813258 | 0.17 | 0.17 | 1 | 10991 | TE Connectivity AMP Connectors | 0.17 @ Qty: 1+ |
