mpn:
manufacturer:
MPN:
Preferred Price:
2.63
Price:
2.63
Min Simple Price:
0.47
Absolute Min Price:
1.87
Min Price:
1.87
Dimensions:
[1.0, 1.0, 1.0]
qty:
11141
simpleSku:
NjI5OA:::5176264-3
sku:
NjI5OA::WI:5176264-3@y0
condition:
11
seller:
Zoro
amzMan:
te connectivity
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Applications, Contact Finish Thickness - Post, Current Rating (Amps), Features, Ingress Protection, Mated Stacking Heights | - |
| Base Product Number | 5176264 |
| Category | Connectors, Interconnects |
| Connector Type | Header, Breakaway |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Tin |
| Contact Finish Thickness - Mating | 30.0?in (0.76?m) |
| Contact Length - Mating | 0.157" (4.00mm) |
| Contact Length - Post | 0.102" (2.60mm) |
| Contact Material | Brass |
| Contact Shape | Square |
| Contact Type | Male Pin |
| Country of Origin (subject to change) | Singapore |
| Description | CONN HEADER VERT 8POS 2MM |
| Detailed Description | Connector Header Through Hole 8 position 0.079" (2.00mm) |
| Digi-Key Part Number | 5176264-3-ND |
| Fastening Type | Push-Pull |
| Insulation Color | Black |
| Insulation Height | 0.059" (1.50mm) |
| Insulation Material | Thermoplastic |
| Manufacturer Product Number | 5176264-3 |
| Manufacturer, Mfr | TE Connectivity AMP Connectors |
| Material Flammability Rating | UL94 V-0 |
| Mounting Type | Through Hole |
| Number of Positions | 8 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Operating Temperature | -40?C ~ 105?C |
| Overall Contact Length | 0.319" (8.10mm) |
| Package | Tray |
| Pitch - Mating, Row Spacing - Mating | 0.079" (2.00mm) |
| Product Status | Active |
| Series | AMPMODU |
| Shrouding | Unshrouded |
| Style | Board to Board or Cable |
| Termination | Solder |
| Voltage Rating | 200VAC |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Hotenda | H1467538 | 0.46404 | 69.791616 | 1 | 250 | TE Connectivity AMP Connectors | 0.46404 @ Qty: 250+ | |||
 | Zoro | G201043643 | 0.47 | 74.072 | 19 | 250 | 75 | Te Connectivity | 0.47 @ Qty: 250+ | |
| Waldom | TE CONNECTIVITY AMP BRAND 5176264-3 | 1.05 | 180.6 | 55 | 11141 | TE CONNECTIVITY/AMP BRAND | 1.05 @ Qty: 250+ | |||
 | Digi-Key | 2263375 | 1.498 | 257.656 | 55 | 11141 | TE Connectivity AMP Connectors | 1.498 @ Qty: 250+ |
