mpn:
manufacturer:
MPN:
Weight:
0.01
Weight:
0.01 LB
Preferred Price:
308.86
Price:
308.86
Min Simple Price:
174.5
Absolute Min Price:
247.79
Min Price:
247.79
Dimensions:
[2.0, 1.0, 1.0]
qty:
21
simpleSku:
DA1MjQ:::1-1393817-2
sku:
DA1MjQ::MA:1-1393817-2@y0
condition:
11
seller:
Onlinecomponents.com
amzMan:
te connectivity
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Alternate Mfr Part Number | 1-1393817-2 |
| Body Depth - Relay | 0.945 in |
| Body Height - Relay | 1.181 in |
| Body Width - Relay | 0.512 in |
| Coil Current | 60 mA |
| Coil Insulation, Features, Must Release Voltage, Seal Rating | - |
| Coil Resistance | 400 Ohms, 400 ? |
| Coil Type | Bistable, 2 Coils, Polarized, Latching, Dual Coil |
| Coil Voltage | 24VDC |
| Contact Form | DPST-NO/NC (1 Form A, 1 Form B) |
| Contact Limiting Breaking Current, Contact Limiting Continuous Current, Contact Limiting Making Current, Contact Limiting Short-Time Current | 5A |
| Contact Material | Silver (Ag) |
| Contact Rating (Current) | 5 A |
| Contact Voltage Rating, Switching Voltage | 250 VAC [ 250 VDC ] |
| Dielectric Voltage | 1000 Vrms Adjacent Contacts; 1000 Vrms Open Contacts |
| Electrical Connection - Power Relay | Solder Terminals |
| Features | BIFURCATED/Twin Contacts |
| Item - Relay | Cradle P Relay |
| Mfr | TE Connectivity Potter & Brumfield Relays |
| Mounting Type | Socketable |
| Must Operate Voltage | 16.5 VDC |
| Number of Poles | 2 |
| Operating Temp. Range | -40 to 70 ?C |
| Operating Temperature | -40?C ~ 70?C |
| Package Quantity | 1 |
| Part Status | Active |
| Power Consumption - Relay | 1500 mW |
| Protection Category | RTI |
| Relay Type | General Purpose |
| Switching Voltage | 250VAC, 250VDC - Max |
| Termination Style | Plug In |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Onlinecomponents.com | 1-1393817-2 | 174.5 | 174.5 | 1 | In Stock | TE Connectivity / AMP Brand | 174.5 @ Qty: 1+ | |||
| Digi-Key | 2398410 | 247.159 | 2125.5674 | 20 | In Stock | te-connectivity-potter-brumfield-relays | 247.159 @ Qty: 20+ | |||
 | Zoro | G805865900 | 256.99 | 256.99 | 1 | In Stock | Te Connectivity | 256.99 @ Qty: 1+ | ||
| us.rs-online.com | 72129492 | 264.17 | 1215.182 | 10 | In Stock | TE Connectivity | 264.17 @ Qty: 10+ | |||
| Newark | 35AC6189 | 274.73 | 274.73 | 1 | In Stock | AMP - TE CONNECTIVITY | 274.73 @ Qty: 1+ |
