| Accuracy | +/-0.5% |
| Accuracy - Transmitter | +/-0.50% |
| Compatible With | Refrigeration Fluids, Gas, Hydraulic, Air, Fresh Water |
| Country of Origin (subject to change) | Germany |
| Electrical Connections | Packard (3-Pin) |
| Electrical Connections - Transmitter | 3 Pin Packard Connector |
| Item, Transmitter Type | Pressure Transmitter |
| Max. Pressure (PSI) | 300 |
| NEMA Rating | 1 |
| Operating Temp. | -30 to 100 Degrees C |
| Operating Temp. - Transmitter | -30 Degrees to 100 Degrees C |
| Output | 0 to 10V |
| Output - Transmitter | 0 to 10VDC |
| Power Required | 24VDC |
| Power Required - Transmitters | 14 to 30V DC |
| Process Connection | 1/4"-18 MNPT |
| Process Connection Size - Transmitter | 1/4" |
| Process Connection Type - Transmitter | MNPT |
| Range | 0 to 150 psi |
| Range Units - Transmitter | psi |
| Range Values - Transmitter | 0 to 150 |
| Safety Rating | 450 psi |
| Wetted Materials | 17-4PH Stainless Steel, AISI 304 Stainless Steel |
| Wetted Materials - Transmitters | 17-4PH Stainless Steel, 304 Stainless Steel |
| Wiring Entry - Transmitter | None |
