TELEMECANIQUE SENSORS XS212BLNAL2

B00CONH6T4

Telemecanique XS212BLNAL2 Inductive Proximity Sensor, Flush Mount, Metal 12-mm Barrel, for Light Industry, 2-Wire AC/DC Wiring, PNP Input, NO Output, 2-m Electrical Cable

Telemecanique XS212BLNAL2 Inductive Proximity Sensor, Flush Mount, Metal 12-mm Barrel, for Light Industry, 2-Wire AC/DC Wiring, PNP Input, NO Output, 2-m Electrical Cablezoom

Attributes

Key Value
ApplicationGENERAL PURPOSE
Basic Proximity Sensor .Metal
Body StyleCylindrical
BrandTelemecanique
Case MaterialNickel Plated Brass
Catalog NumberXS212BLNAL2
ConnectorCable
Control OutputDC 3-WIRE (NPN) - 1 N.O.
Country of OriginIndonesia
Description/Special Fea.Overload And Short-Circ.
EnclosureNickel Plated Brass
GTIN00785901803966, 0338911.
IndicatorOutput state 1 LED yell.
IP Rating67
ItemCylindrical Proximity S.
Item TypeInductive proximity sen.
Length41 mm
Length (Straight Wirewa.41 mm
Made in USANO
ManufacturerSchneider Electric
MaterialMetal
Max. Current Load100mA
Max. Detecting Distance4 mm
Measurement Range0 to 3.2 mm, 4 mm
MountingFlush
Mounting StyleFlush Shielded
Mounting TypeM12 x 1 Threaded
NEMA Rating4X
Operating Temp. Range-13 Degrees to 158 Deg.
Operating Temperature-25-70 A Degrees C
OutputNPN
Output ModeNO
Primary TypeInductive Proximity Sen.
Promotion RestrictionNot eligible for promot.
Proximity Sensing MethodInductive
Proximity Sensor Diamet.12 mm
Proximity Sensor Electr.2m Cable
Proximity Sensor Operat.1,000 Hz
Proximity Sensor Output.3 Wire NPN
Proximity Sensor Power .12 to 24V DC
Proximity Sensor StyleCylindrical Proximity S.
Sensing Range4 MM,> 0.1...0.16 IN (>.
Sensor12 MM,44 MM,INDUCTIVE P.
SeriesXS200 Series
Shielded / UnshieldedUnshielded
ShieldingShielded
Special FeaturesMetal
StandardIP67 conforming to IEC .
StandardsCE Compliance, CSA Cert.
Sub BrandXS2
Supply Voltage10-36 VDC, 12...24 V DC.
Switching Capacity<= 200 mA overload and .
UPC785901803966
UPC Code785901803966
Warranty DescriptionContractual Warranty:18.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG075628735.4515Telemecanique Sensors0.1535.45 @ 5
thumbzoomNewark09P756344.1215TELEMECANIQUE SENSORS44.12 @ 5
thumbzoomsustainablesupply.comC116633845.5615Telemecanique Sensors0.1545.56 @ 5
us.rs-online.com7000756046.5815Telemecanique Sensors46.58 @ 5
thumbzoomcrescentelectric.com110702550.6615Telemecanique50.66 @ 5
Grainger1EWC862.3150TELEMECANIQUE SENSORS62.3 @ 5
thumbzoomRaptor SuppliesAG9FPQ96.483172515TELEMECANIQUE SENSORS96.4831725 @ 5
