Telemecanique / Schneider Electric XS7C2A1MAU20

B011ON3NX2

SCHNEIDER ELECTRIC / TELEMECANIQUE XS7C2A1MAU20 PROXIMITY SENSOR, INDUCTIVE, 15MM, 24-240VAC/DC

SCHNEIDER ELECTRIC / TELEMECANIQUE XS7C2A1MAU20 PROXIMITY SENSOR, INDUCTIVE, 15MM, 24-240VAC/DCzoom

Attributes

Key Value
Application-
Basic Proximity Sensor .Plastic
BrandTelemecanique
Case MaterialPlastic
Catalog NumberXS7C2A1MAU20
ConnectorMale connector 1/2"20 U.
Country of OriginIndonesia
Country of Origin (subj.Indonesia
Depth70 mm
Description/Special Fea.1 Green LED for Supply .
EnclosurePBT
IndicatorSupply on 1 LED green);.
IP Rating65, 67, 69K
ItemRectangular Proximity S.
Item TypeInductive proximity sen.
Length40 mm
Length (Straight Wirewa.40 mm
Made in USANO
ManufacturerSchneider Electric
MaterialPlastic
Max. Current Load200mA
Max. Detecting Distance15.0 mm
MountingFlush
Operating Temp. Range-13 Degrees to 158 Deg.
Operating Temperature-25-70 A Degrees C
Output ModeNO
Primary TypeInductive Proximity Sen.
Proximity Sensing MethodInductive
Proximity Sensor Electr.3 Pin 1/2-20 UNF Male C.
Proximity Sensor Operat.25 Hz AC/50 Hz DC
Proximity Sensor Output.2 Wire
Proximity Sensor Power .24 to 240V AC/DC
Proximity Sensor StyleRectangular Proximity S.
Sensing Range15 MM,> 0.31...0.59 IN .
Sensor40 MM,40 MM,INDUCTIVE P.
SeriesXS7C Series
Shielded / UnshieldedShielded
ShieldingShielded
Special FeaturesPlastic
StandardIP67 conforming to IEC .
StandardsCCC, CE Compliance, CSA.
Sub BrandXS7
Supply Voltage24...240 V AC 50/60 Hz;.
UPC785901093596
UPC Code785901093596
Warranty DescriptionContractual Warranty:18.
Width40 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG456388587.01In Stock38Telemecanique Sensors0.3187.0 @ 1
thumbzoomsustainablesupply.comC1189549189.11In StockTelemecanique Sensors0.31189.1 @ 1
us.rs-online.com70274179222.21In StockTelemecanique Sensors222.2 @ 1
thumbzoomNewark47W9324223.821In StockTELEMECANIQUE SENSORS223.82 @ 1
thumbzoomRaptor SuppliesAH3HWM248.75563051In StockTELEMECANIQUE SENSORS248.7556305 @ 1
thumbzoomcrescentelectric.com1157698270.871In StockTelemecanique270.87 @ 1
