TRACOPOWER TMR 9-4821WI

B01D0Z7BM6

TMR 9-4821WI?-?Isolated Board Mount DC/DC Converter, 2 Output, 9 W, 5 V, 800 mA, -5 V, 800 mA

TMR 9-4821WI?-?Isolated Board Mount DC/DC Converter, 2 Output, 9 W, 5 V, 800 mA, -5 V, 800 mAzoom

Attributes

Key Value
ApplicationsITE (Commercial)
Approval AgencyCB, cURus
Body dimensions21.8x11.2x9.6mm
CaseSIP8
Current - Output (Max)800mA, 800mA
Efficiency85%
FeaturesRemote On/Off, SCP
Input voltage18...75V
Insulation voltage1600V
ManufacturerTRACO POWER
Manufacturer seriesTMR 9WI
MfrTRACO POWER
Mounting TypeThrough Hole
Number of outputs2
Number of Outputs2
Operating Temperature-40?C ~ 85?C (With Dera.
Operating temperature-40...85?C
Output current800mA
Output current 2800mA
Output voltage5V DC
Output voltage 2-5V DC
Package / Case8-SIP Module, 6 Leads
Part StatusActive
Power9W
Power (Watts)8 W
Protectionanti-overload OPP,
Size / Dimension0.86" L x 0.38" W x 0.4.
Supplier Device Package-
Switching frequency400kHz
TypeIsolated Module
Type of converterDC/DC
Voltage - Input (Max)75V
Voltage - Input (Min)18V
Voltage - Isolation1.6 kV
Voltage - Output 15V
Voltage - Output 2-5V
Voltage - Output 3-
Voltage - Output 4-

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomDigi-KeyTMR9-4821WI-ND37.77610In StockTraco Power37.776 @ 10
thumbzoomNewark45Y309938.25110TRACO POWER38.25 @ 1
TMETMR9-4821WI40.951In StockTRACO POWER40.95 @ 1
RS Delivers873-216556.1841In StockTRACOPOWER56.184 @ 1
