- mpnUCFL206-18
- brandname: TRITAN
- manufacturername: TRITAN
UCFL206-18 - TRITAN - Factory New!
- Brand: Tritan
- PartNumber: UCFL206-18
- PackageQuantity: 1
- Manufacturer: TRITAN
- Label: TRITAN
Attributes
| Key | Value |
|---|
| Bearing Housing Materia. | Cast Iron |
| Bearing Insert Material | 52100 Steel, Alloy Steel |
| Bearing Insert Type | Ball, Radial Ball |
| Bearing Lubrication | Shell Alvania RL2 or NL. |
| Bearing Material Grade | 52100 |
| Bolt Hole Center-to-Cen. | 4.6063" |
| Bolt Size | 3/8 in |
| Bore Dia. | 1.125" |
| Bore Diameter | 1 1/8 in |
| Bore Type | Cylindrical |
| Brand | Tritan |
| Closure | Double Sealed |
| Color | Grey |
| Current Stock | 97 |
| Dynamic Load Capacity | 4383 Lbf, 4,383.77 lbf |
| Features | Anti-Rotation Device, C. |
| Finish | Painted |
| Flange Thickness | 0.5 in |
| Housing Material | Cast Iron |
| Housing Material Finish | Painted |
| Housing Type | Rhombus |
| Included Bearing | UC206-18 |
| International Shipping | No |
| Item | 2 Bolt Flange Bearing, . |
| Lead Time | Expected to ship in 1-2. |
| Locking Type | Set Screw |
| Lubricant Material | NLGI #2 Equivalent |
| Lubrication Openings | One Zirc Fitting |
| Maximum Temperature | 250 Degrees F |
| Minimum Temperature | -40 Degrees F |
| Mount Hole Center-to-Ce. | 4 39/64 in, 4.609 in |
| Mount Hole Size | 7/16 in |
| Mounting Bolt Size | 3/8 in |
| Mpn | UCFL206-18 |
| Number of Mount Holes | 2 |
| Overall Height | 40.2 mm, 1.593 in |
| Overall Length | 148 mm, 5.812 in |
| Overall Width | 3.156 in, 80 mm |
| Rolling Element Rows | 1 |
| Seal Material | Rubber |
| Series | UCFL |
| Shaft Locking Type | Set Screw, Set Screws |
| SKU | ZO-G9447112 |
| Standards | ISO, AFBMA, AFBMA, ISO |
| Static Load Capacity | 2540 Lbf |
| Static Radial Load Capa. | 2,540.34 lbf |
| SubCategory | Power Transmission |
| System of Measurement | Inch |
| Temp. Range | -4 to +248? F |
| UPC | 888569051332 |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
 | Zoro | G9447112 | 22.25 | 1 | 188 | | Tritan | 1.9 | 22.25 @ 1 |
| AmazonSC | B076HFQRCX | 30.82 | 1 | In Stock | | Tritan | | 30.82 @ 1 |
 | simsupply.com | ZO-G9447112 | 33.61 | 1 | 97 | | Tritan | | 33.61 @ 1 |
 | Global Industrial | WBB1873207 | 38.7 | 1 | In Stock | | Tritan | | 38.7 @ 1 |
| grainger.ca | WWG36UY71 | 50.39271058 | 1 | In Stock | | TRITAN | 1.9 | 50.39271058 @ 1 |
 | Raptor Supplies | AH7JYW | 66.4711515 | 1 | In Stock | | TRITAN | | 66.4711515 @ 1 |
