mpn:
brand:
manufacturer:
MPN:
Weight:
2.2
Weight:
2.2 LB
Preferred Price:
116.22
Price:
116.22
Min Simple Price:
63.51
Absolute Min Price:
90.18
Min Price:
90.18
Dimensions:
[4.0, 3.0, 1.0]
qty:
21
simpleSku:
MTUwNA:::50ASK1RL
sku:
MTUwNA::VO:50ASK1RL@y0
condition:
11
seller:
Zoro
amzMan:
tsubaki
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Agency Compliance | American National Standards Institute (ANSI) |
| ANSI Chain Size | 50AS |
| Attachment Number, Roller Chain Link Type | K-1 |
| Attachment Type | Tab |
| Centerline to Attachment End, Connecting End to Center Line | 0.472 in |
| Centerline to Hole Center, Rivet End to Center Line | 0.406 in |
| Chain Link Material | 600 Stainless Steel |
| Chain Link Overall Width, Chain Overall Width, Pin Length | 0.878 in |
| Chain Number, For Chain Number, Industry Chain Size | 50 |
| Chain Roller Dia. | 0.4 in |
| Connecting End to Center Line (In.) | 0.472 |
| Country of Origin (subject to change) | Japan |
| Extended Pin Diameter, Inside Pin Dia., Outside Pin Dia. | 0.2 in |
| For Chain Style | Stainless Steel Roller Chains |
| For Chain Style (combined) | 50 Plain Stainless Steel |
| Industry Chain Pitch | 5/8 in |
| Item, Link Style, Link Type, Roller Chain Link Item | Roller Attachment Link |
| Length (In.) | 0.625 |
| Lubrication | SAE 10 to SAE 50 |
| Material | Stainless Steel |
| Material Grade | 600 |
| Max. Allowable Load | 231 lb |
| Max. Allowable Load (Lb.) | 231 |
| Maximum Operating Temperature | 750 Degrees F |
| Minimum Operating Temperature | -40 Degrees F |
| Number of Strands, Number of Strands (broad rename) | Single |
| Number of Tab Holes | 1 |
| Outside Pin Dia. (In.) | 0.200 |
| Overall Width (In.), Pin Length (In.) | 0.878 |
| Pin Contruction | Riveted Pin |
| Pin Link Plate Thickness | 0.08 in |
| Pin Link Plate Thickness (In.) | 0.080 |
| Pin Type | Riveted |
| Pitch | 0.625" |
| Plate Height, Roller Link Plate Height | 0.591 in |
| Plate Thickness, Width Between Roller Link Plates | 0.375 in |
| Rivet End to Center Line (In.) | 0.406 |
| Roller Dia. (In.) | 0.400 |
| Roller Diameter | 25/64 in |
| Roller Link Plate Height (In.) | 0.591 |
| Standards | ANSI |
| Temp. Range | -40 Degrees to 750 Degrees F |
| Type | K-1 Attachment |
| Width Between Roller Link Plates (In.) | 0.375 |
