Key ^ | Value |
---|---|
Adjustable Angle Instructions | 1. Use 3mm Hex Wrench (A) to loosen two screws (B) by turning one circle counter-clockwise. Then proceed with the adjustment 2. Once you have aligned the door, re-tighten two screws (B) |
Angle Degree, Type | 135 Degree |
Closing Type | Self-Centering 0? Return with Adjustment Up to 30? In or Out |
Designed For | 3/8" and 1/2" (10 and 12 mm) Glass |
Finish | Satin-Brass |
Hardware Includes | Matching Finish Stainless Steel Mounting Screws and Allen Wrench |
Height | 4 |
Material | Solid Forged Brass |
Mounting Style | Glass-to-Glass mount |
Other Specifications | Maximum door weight: - 2-hinge - 100 lbs - 3-hinge - 150 lbs (68 kg) Maximum door width: - 2-hinge - 36" (914 mm) - 3-hinge - 36" (914 mm) |
Pack Size | 1 |
Self-Closing | From 25 Degrees |
