Attributes
| Key ^ | Value |
|---|---|
| ANSI Code, ANSI Number | S08M SDXCL2 |
| Bar Dia. | 0.500" |
| Cutting Direction, Left/Right Hand | Left Hand |
| Cutting Edge Type, Lead Angle | 5 Degrees |
| For Use With | DCMT 21.51 |
| Inscribed Circle | 1/4" |
| Insert Clearance Angle | 7 Degrees |
| Insert Inscribed Circle | 1/4 in |
| Insert Shape | 55 Degrees Diamond |
| Insert Size | 21.51 |
| Insert Thickness | 0.0937" |
| Item | Indexable Boring Bar |
| Min. Bore | 0.720" |
| Min. Bore Dia. | 0.7200 in |
| Mounting Style | Screw Lock |
| Overall Length | 6 in |
| Rake | Positive |
| Shank Dia. | 1/2 in |
| Shank Material | High Speed Steel |
| Style | Solid |
| Type | Turning |
