mpn:
brand:
manufacturer:
MPN:
Weight:
22.34375
Weight:
22.34375 LB
Preferred Price:
3926.53
Price:
3926.53
Min Simple Price:
2218.38
Absolute Min Price:
3150.09
Min Price:
3150.09
Dimensions:
[30.0, 23.0, 21.0]
qty:
21
simpleSku:
OTIwNg:::U30P2D
sku:
OTIwNg::6U:U30P2D@y0
condition:
11
seller:
emotorpro.com
amzMan:
us motors
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Amps, FL Amps | 78-70/35 |
| Bearings | Ball |
| Brand | U.s. Motors |
| Color | Black |
| Composition, Construction | Aluminum |
| Current Stock, Phase | 3 |
| Drive End Flange Type | Standard |
| Efficiency | 93.6% |
| Enclosure | TEFC, Totally Enclosed Fan Cooled |
| Enclosure Type | TEFC (Totally Enclosed Fan Cooled) |
| Estimated Weight | 357.50 |
| Family Series | US Motors Motors |
| FL Efficiency | 93.6 |
| Frame, NEMA Frame | 286T |
| Frequency | 60 Hz |
| Gross Weight | 325 lbs |
| Hertz | 50, 60 |
| Horsepower | 30 hp |
| HP | 30 |
| Hz | 50/60 |
| Insulation Class | F |
| International Shipping | No |
| Item | General Purpose Motor |
| Item Number, Manufacturer Part Number, Mpn, Part Number | U30P2D |
| Kilowatts | 22.4 kW |
| Lead Time | Expected to ship in 1-2 business days |
| Length Less Shaft | 23 11/16 in |
| Manufacturer | US Motors (Nidec), US Motors |
| Manufacturer Model #, Model Number | CN07 |
| Manufacturers Warranty Length | 2 yr |
| Maximum Ambient Temperature | 40? C |
| Motor Application | General Application |
| Motor Design | 3-Phase |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Frame Material | Cast Aluminum |
| Motor Mounting Position | Horizontal or Vertical Shaft Down |
| Motor Mounting Type | Rigid Base |
| Motor Service Factor, Service Factor | 1.25 |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Mounting | Base |
| Mounting, Mounting Type | Foot Mount |
| Nameplate RPM | 1,800 |
| Net Weight | 20.3125 lbs |
| No. of Speeds, Number of Speeds | 1 |
| Nominal Voltage | 208 VAC, 240 VAC, 480 VAC |
| Number of Poles | 4 |
| Overall Length | 27 5/16 in |
| Product Type | General Purpose, Three Phase |
| Rotation | Reversible |
| RPM | 1,770 RPM |
| RPM Range | 1,701-1,800 |
| RPM, Speed (RPM) | 1770 |
| Shaft Dia. | 1 7/8 in |
| Shaft Length | 4 5/8 in |
| Ship Weight | 325 lbs. |
| SKU | ZO-G4591876 |
| Standards | CE, CSA, UL |
| SubCategory | Motors/Ac Motors |
| Voltage | 190V, 230V, 380V, 460V, 230/460V AC |
| Voltage (AC) | 208-230 VAC, 460 VAC |
| Voltage Compatibility | 200-230/440V AC, 200-230/460V AC, 208-220/440V AC, 208-230/460V AC, 230/460V AC |
| Volts | 208, 230, 460 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
 | emotorpro.com | U30P2D | 2218.38 | 2218.38 | 1 | In Stock | U.S. Motors | 325.0 | 2218.38 @ Qty: 1+ | |
 | motorsandcontrol.com | U30P2D | 2290.6 | 2290.6 | 1 | In Stock | US Motors (Nidec) | 357.5 | 2290.6 @ Qty: 1+ | |
 | Zoro | G4591876 | 2440.99 | 2440.99 | 1 | 1 | U.S. Motors | 325.0 | 2440.99 @ Qty: 1+ | |
 | sustainablesupply.com | C1549365 | 2535.29 | 2535.29 | 1 | In Stock | US Motors | 325.0 | 2535.29 @ Qty: 1+ | |
 | Galco | U30P2D-USM | 2596.19 | 2596.19 | 1 | In Stock | US Motors | 325.0 | 2596.19 @ Qty: 1+ | |
 | simsupply.com | ZO-G4591876 | 2888.61 | 2888.61 | 1 | 3 | U.s. Motors | 2888.61 @ Qty: 1+ | ||
| motionindustries.com | 04392898 | 3656.62 | 3656.62 | 1 | In Stock | US Motors (Nidec) | 3656.62 @ Qty: 1+ |
