Diode, Bridge Rectifier, Vr 200V, If 35A, Pkg D-63, Vf 1.19V
Weight:
0.00275625
Weight:
0.04 LB
Preferred Price:
21.11
Price:
21.11
Min Simple Price:
11.3
Absolute Min Price:
16.48
Min Price:
16.48
Dimensions:
[2.0, 1.0, 1.0]
qty:
21
simpleSku:
TQzMDY:::VS-36MT20
sku:
TQzMDY::ZA:VS-36MT20@y0
condition:
11
seller:
Galco
amzMan:
vishay pcs
HazMat:
False
DropShip:
False
Attributes
| Key ^ | Value |
|---|---|
| Average Current, Current - Average Rectified (Io), Forward Current | 35 A |
| Base Product Number, Item Number | 36MT20 |
| Bridge Type, Configuration, Diode Type | Three Phase |
| Case, Supplier Device Package | D-63 |
| Category | Discrete Semiconductor Products |
| Circuit | Full Wave Diode Bridge |
| Current - Reverse Leakage @ Vr | 10 ?A @ 200 V |
| Current Squared Time Rating | 1130 A sq. s |
| Dimensions | 28.5 x 28.5 x 10 mm |
| Diode Type | Power Bridge Rectifier |
| Electrical mounting | THT |
| Family Series | Vishay Bridge Rectifiers, MT Series |
| Forward Voltage | 1.19 V |
| Gross Weight, Net Weight | 0.0441 lbs |
| Height | 0.394" (10mm) |
| Isolation Barrier Incl. | No |
| It (avg) | 35 |
| Kind of package, Package | bulk |
| Leads | connectors 6,3x0,8mm |
| Length | 1.122 in |
| Load current | 35A |
| Manufacturer | Vishay |
| Manufacturer Part Number | VS-36MT20 |
| Max. forward impulse current | 475A |
| Max. forward voltage | 1.19V |
| Max. off-state voltage | 200V |
| Maximum Junction Temperature, Maximum Operating Temperature | +150 ?C |
| Mfr | Vishay General Semiconductor - Diodes Division |
| Minimum Operating Temperature | -55 ?C |
| Mounting Type | QC Terminal, Through Hole |
| Non Repetitive On State Peak Current, Surge Current | 500 A |
| Number of Pins | 5 |
| Operating Temperature | -55?C ~ 150?C (TJ) |
| Operating Temperature, Temperature Operating Range | -55 to +150 ?C |
| Package / Case | 5-Square, D-63 |
| Package Type | D 63 |
| Part Status | Active |
| Peak Current, Reverse Current | 100 ?A |
| Primary Type | Bridge Rectifier |
| Product Header | Three Phase Bridge Rectifier Diode |
| Product Series | MT |
| Repetitive Peak Voltage, Voltage - Peak Reverse (Max), Vrrm | 200 V |
| Resistance, Thermal, Junction to Case | 1.35 K/W |
| RMS Voltage | 275 V |
| RoHS | Yes |
| Series | -, VS-36MT Series |
| Technology | Standard |
| Termination | 0.250 inch Quick Connect, 5 Pin Solder |
| Type of bridge rectifier | three-phase |
| Version | square |
| Width | 0 in |
