<p><strong>W.E. Anderson, WE35-DDA02-T2, 3-Way NPT Brass Ball Valve, 3/4in Double Acting, Flow Path B </strong> </p> <p>The SERIES WE35 incorporates a full port 3-way brass ball valve for great flow rates with minimal pressure drop. The valve features a blowout proof stem for added safety, reinforced PTFE seats and seals for longer life, and a brass ball for better performance. Actuators are direct mounted creating a compact assembly for tight spaces. </p>
Attributes
| Key ^ | Value |
|---|---|
| Accessory Mounting | NAMUR standard |
| Agency Approvals | Meets the technical requirements of EU Directive 2011/65/EU (RoHS II) |
| Air Connections | 1/4" female NPT |
| Body | 3-way |
| End Connections | Female NPT |
| Housing Material | Anodized aluminum body and epoxy coated aluminum end caps |
| Line Sizes | 3/4 |
| Maximum Supply Pressure | 120 psi (8.6 bar) |
| Normal Supply Pressure | 40 to 115 psi (2.7 to 7.9 bar) |
| Other Materials | O-ring: NBR; Handle, stem nut, ferrule: SS; Handle Sleeve: Vinyl; Body and cap: Nickle plated |
| Pressure Limits | 600 psi (41 bar) WOG |
| Service | Compatible liquids and gases |
| Temperature Limits | -40 to 176?F (-40 to 80?C), -20 to 425?F (-30 to 220?C) |
| Type | double acting |
| Wetted Materials | Body, ball, and stem: Brass; Seat, seal, and packing: PTFE |
