mpn:
brand:
manufacturer:
MPN:
Weight:
0.001344475
Weight:
0.001344475 LB
Preferred Price:
119.19
Price:
119.19
Min Simple Price:
6.24
Absolute Min Price:
93.6
Min Price:
93.6
Dimensions:
[88.0, 6.0, 6.0]
qty:
1
simpleSku:
zk0Nzg:::2002-1871
sku:
zk0Nzg::I2:2002-1871@y1
condition:
11
seller:
Platt.com
amzMan:
wago
HazMat:
False
DropShip:
True
Attributes
| Key ^ | Value |
|---|---|
| Actuation type | Push-in || Operating tool |
| Actuator | Operating tool |
| Approvals per | UL 1059 |
| Brand, Manufacturer | WAGO |
| Catalog Number, Item Number | 2002-1871 |
| Color | Gray |
| Conductor Material | Copper |
| Conductor Range | 12-22 AWG Conductor Range |
| Connection | Terminals (Cage-clamp) |
| Connection technology | Push-in CAGE CLAMP? |
| Country of Origin | China |
| Country of origin | CN |
| CSA Current | 10 A |
| CSA Voltage | 600 V |
| Current Rating, IEC Current, Rated current | 16 A |
| Depth | 87.5?mm?/ 3.445?inch |
| Dimensions | H87.5mm x W5.2mm x D32.9mm |
| Family Series | Wago Terminal Blocks, 2002 Series |
| Gross Weight, Net Weight | 0.02 lbs |
| GTIN, UPC | 4045454974855 |
| Height | 87.5 mm / 3.445 inches |
| Height UOM, Width UOM | Inch |
| IEC Voltage | 400 V |
| Insulation material, Material | Polyamide (PA66) |
| Item Type | Terminal |
| Made in USA, Partition | No |
| Manufacturer Part Number | 51222028 |
| Max CSA Wire Size (AWG), Max UL Wire Size (AWG) | 12 AWG |
| Max IEC Wire Size (mm2) | 4 Mm2 |
| Mounting type | DIN-35 rail |
| Mounting, Mounting Type | Din Rail |
| Nominal Cross Section | 2.5 mm? |
| Nominal cross-section | 2.5?mm? |
| Number of Circuits | 2 |
| Product Series | 2002 |
| RoHS, RoHS Indicator | Yes |
| Sensor Block Indicator | None |
| Solid conductor | 0.25 ? 4?mm??/ 22 ? 12?AWG |
| Spacing | 5.2 mm |
| Total number of connection points | 4 |
| Type | Disconnect Block |
| UL Current | 15 A |
| UL Voltage | 300 V |
| Voltage Rating | 400 |
| Weight | 9.778, 9.778 g |
| Weight UOM | Grams |
| Width | 0.205, 5.2?mm?/ 0.205?inch |
| Wire Entry Position | Top |
| Wiring type | Front-entry wiring |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Platt.com | 0303392 | 6.24 | 39.936 | 1 | 12 | Wago | 6.24 @ Qty: 10+ | |||
 | standardelectricsupply.com | 2208791 | 6.55 | 41.92 | 1 | 10 | Wago | 0.0215116 | 6.55 @ Qty: 10+ | |
 | Galco | 2002-1871-WAGO | 6.87 | 178.62 | 50 | 10 | Wago | 0.02 | 6.87 @ Qty: 50+ | |
 | crescentelectric.com | 1016627 | 7.1 | 45.44 | 1 | 10 | WAGO | 7.1 @ Qty: 10+ | ||
 | Newark | 97M6772 | 10.36 | 66.304 | 1 | 10 | WAGO | 10.36 @ Qty: 10+ |
