Attributes
| Key ^ | Value |
|---|---|
| Actuation type | Push-in || Operating tool |
| Approvals per | UL 1059 |
| Color | Gray |
| Connection technology | Push-in CAGE CLAMP? |
| Country of origin | CN |
| Depth | 105.1?mm?/ 4.138?inch |
| Insulation material | Polyamide (PA66) |
| Mounting type | DIN-35 rail |
| Nominal cross-section | 2.5?mm? |
| Number of connection points, Number of connection points (connection type) | 4 |
| Potential marking | L/L |
| Rated current | 24 A |
| Solid conductor | 0.25 ? 4?mm??/ 22 ? 12?AWG |
| Total number of connection points | 8 |
| Weight | 16.209 g |
| Width | 5.2?mm?/ 0.205?inch |
| Wiring type | Front-entry wiring |
