Attributes
| Key ^ | Value |
|---|---|
| Actuation type, Actuator | Operating tool |
| Approvals | CB, CSA, UL, UR |
| Approvals per | CSA, UL 1059 |
| Brand, Manufacturer | Wago |
| Catalog Number, Item Number | 231-612/019-000 |
| Color | Gray |
| Comments | Universal Connection for all Conductor Types |
| Conductor entry direction to mating direction | 0 ? |
| Conductor Range | 12-28 AWG Conductor Range |
| Connection | CAGE CLAMP |
| Connection technology | CAGE CLAMP? |
| Connector (connection type) | For conductor |
| Connector Gender | Male |
| Contact Finish | Tin |
| Contact Material | Electrolytic Copper |
| Contact material | Electrolytic copper (ECu) |
| Contact type (pluggable connector) | Male connector/plug |
| Country of Origin | Germany |
| Country of origin | DE |
| Current | 15 A |
| Current Rating | 12 A |
| Depth | 27.5 mm / 1.083 inches, 27.5?mm?/ 1.083?inch |
| Depth UOM, Height UOM, Width UOM | Inch |
| Family Series | Wago Plugs & Receptacles, 231 Series |
| Gross Weight | 0.05 lbs |
| GTIN | 4044918258401 |
| Height | 14.3 mm / 0.563 inches, 14.3?mm?/ 0.563?inch |
| Housing Type | None (Insert Only) |
| Insulation material, Material | Polyamide (PA66) |
| Item Type | 1-conductor male connector |
| Made in USA | No |
| Manufacturer Part Number | 51110834 |
| Mounting | Flange |
| Mounting type | Mounting flange || Feed-through mounting || Panel mounting |
| Net Weight | 0.0425 lbs |
| Number of connection types | 1 |
| Number of Contacts | 12 Pole |
| Product Series | 231 |
| Rated current | 0 |
| Rated Impulse Voltage | 4 kV |
| RoHS Compliant, RoHS Indicator | Yes |
| Size, Wire Size | 28-12 AWG |
| Solid conductor | 0.08 ? 2.5?mm??/ 28 ? 12?AWG |
| Stripping Length | 8-9 mm |
| Temperature | -60-100 ?C |
| Total number of connection points | 12 |
| Voltage | 300 V |
| Voltage Rating | 320 |
| Weight | 19.28, 19.280 g |
| Weight UOM | Grams |
| Width | 74.8?mm?/ 2.945?inch, 2.945 |
All Prices
| Img | Seller | Supplier SKU | Requested Price ^ | Calc MOQ Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|---|---|---|---|---|---|---|---|---|---|
| Onlinecomponents.com | 231-612/019-000 | 7.46 | 109.186 | 1 | 25 | WAGO | 7.09 @ Qty: 26+ | |||
| Radwell | 231612019000 | 7.84 | 120.736 | 1 | 25 | WAGO | 7.84 @ Qty: 25+ | |||
| Platt.com | 0306972 | 9.69 | 149.226 | 1 | 25 | Wago | 9.69 @ Qty: 25+ | |||
 | standardelectricsupply.com | 2286450 | 10.19 | 156.926 | 1 | 25 | Wago | 0.042416 | 10.19 @ Qty: 25+ | |
 | Galco | 231-612/019-000-WAGO | 10.49 | 161.546 | 1 | 25 | Wago | 0.05 | 10.49 @ Qty: 25+ | |
 | crescentelectric.com | 1074050 | 11.04 | 170.016 | 1 | 25 | WAGO | 11.04 @ Qty: 25+ | ||
| Newark | 28K8409 | 14.92 | 229.768 | 1 | 25 | WAGO | 14.92 @ Qty: 25+ | |||
 | Misumi USA | 231-612/019-000 | 24.83 | 382.382 | 1 | 25 | WAGO | 24.83 @ Qty: 25+ |
