| Actuation type | Operating tool |
| Approvals per | CSA, UL 1059 |
| Color | Gray |
| Conductor entry direction to mating direction | 0 ? |
| Connection technology | CAGE CLAMP? |
| Connector (connection type) | For conductor |
| Contact material | Copper alloy |
| Contact type (pluggable connector) | Female connector/socket |
| Country of origin | DE |
| Depth | 29.6?mm?/ 1.165?inch |
| Height | 14.3?mm?/ 0.563?inch |
| Insulation material | Polyamide (PA66) |
| Number of connection types | 1 |
| Rated current | 16 A |
| Solid conductor | 0.08 ? 2.5?mm??/ 28 ? 12?AWG |
| Total number of connection points | 2 |
| Weight | 5.192 g |
| Width | 26.6?mm?/ 1.047?inch |
