| Actuation type | Push-button |
| Approvals per | CSA, UL 1059 |
| Color | Light gray |
| Conductor entry direction to mating direction | 0 ? |
| Connection technology | Push-in CAGE CLAMP? |
| Connector (connection type) | For conductor |
| Contact material | Copper alloy |
| Contact type (pluggable connector) | Female connector/socket |
| Country of origin | PL |
| Depth | 25.6?mm?/ 1.008?inch |
| Height | 15?mm?/ 0.591?inch |
| Insulation material | Polyamide (PA66) |
| Number of connection types | 1 |
| Rated current | 16 A |
| Solid conductor | 0.2 ? 2.5?mm??/ 24 ? 12?AWG |
| Total number of connection points | 2 |
| Weight | 3.510 g |
| Width | 11.5?mm?/ 0.453?inch |
