| ANALOG fixed control | 4-20mA, 0-20mA, 20-4mA, 20-0mA (Proportional to the flow rate) |
| Analog input display | Displays the actual analog input value |
| ANALOG variable control | 2-setpoint programmable (0-20mA, proportional to flow rate) |
| AUX | Pump operates at programmed flow rate with input contact |
| Batch control | 31.2mL/PLS - 600L/PLS |
| Buffer memory | Enables memory or ignoring of incoming pulses during operation in Batch mode |
| Connections | Flange (ANSI 150 lb) |
| Controller Location | Top Back |
| Current | DC 0-20mA, 2 programmable setpoints (Max. resistance load: 300?) |
| Drive Unit/Pump Size | D300: 79.2 GPH (300 LPH) |
| Input Analog | 0-20mA DC (Internal resistance is 200?) |
| Input Pulse | No-voltage contact or open collector. Max pulse frequency: 100Hz |
| Interlock, STOP | Operation stops/starts with input contact |
| Interval batch control | Day: 0 - 9, Hour: 0 - 23, Minute: 1 - 59 |
| Keylock | Locks/unlocks keypad operation with PIN code |
| Keypad | Start/Stop, MENU, ESC, Enter, Up, Down, Left and Right keys |
| MAN (Manual) | Use the UP and DOWN keys to adjust a flow rate |
| Maximum discharge rate | Adjusts maximum flow rate limit of pump |
| Monitor | LCD 16 digits x 2 lines, backlit character LCD / LED WHITE: Pump stopped/waiting. ORANGE: Running, Pre-Stop condition. GREEN: Pump operating. RED: Alarm condition/stopped. |
| Power Cord | USA (115V) |
| Power supply | 12VDC 30mA maximum |
| Power voltage | 100-240VAC 10% 50/60Hz |
| PRIME | Forces max. speed operation by pressing the UP and DOWN keys |
| Profibus control | Communication protocol: Profibus-DP-compliant International standard: EN50170 (IEC61158) |
| Pulse control | 0.0312mL/PLS - 600mL/PLS |
| STOP/Pre-Stop/AUX/Interlock | No-voltage contact or open collector |
| Wet End Material | PVDF/FKM/CE |
