| ANSI Code, ANSI Number, ISO Number | ADMT120408R-D56 WKP25S |
| Cast Iron (K) Compatibility, Chip-Breaker, Steel (P) Compatibility, Wiper Insert | Yes |
| Chip-Breaker Code | D56 |
| Chip-Breaker Style | 10 Degrees Chipbreaker Groove |
| Clearance Angle | 15 Degrees |
| Coating, Coating Process | CVD |
| Corner Radius | 0.80mm |
| Country of Origin (subject to change) | Germany |
| Cutting Application, Insert Application | Medium |
| Cutting Direction | Right Hand |
| Cutting Edge Length | 13.60mm |
| Feed Type | High |
| Finish - Machining | TiCN+Al2O3+TiCN |
| For Use With | Xtra?Tec Milling Cutter |
| Grade, Manufacturer Grade | WKP25S |
| Hardened (H) Compatibility, Non Ferrous (N) Compatibility, Stainless (M) Compatibility, Super Alloy (S) Compatibility | No |
| Hole Type | Countersink Hole |
| Included Angle | 85 Degrees |
| Inscribed Circle | .331 in |
| Insert Holding Type, Mounting Style | Screw Held |
| Insert Material, Material - Machining | Carbide |
| Insert Shape, Shape | Parallelogram |
| Insert Size | 120408 |
| Insert Style | ADMT |
| Insert Thickness | 0.187" |
| Item | Parallelogram Milling Insert |
| Measurement System | Metric |
| No. of Edges, Number of Cutting Edges | 2 |
| Nose Radius | 0.031" |
| Primary Material Application | Cast Iron, Steel |
| Primary Material Application ISO Code | K, P |
| Rake | Positive |
| Thickness | 0.187 in |
| Width | 8.40mm |
| Workpiece Compatibility | Cast Iron (K), Steel (P) |
