| ANSI Code | 6939143110 |
| Coolant Fed | Non-Coolant Through |
| Country of Origin (subject to change) | India |
| Cutting Application | Turning |
| Cutting Direction | Right Hand |
| Cutting Height | 1.3380 in |
| Features | Rigid Support to the Insert to Withstand Severe Roughing Cuts on Work-Hardened Wheels, Robust Lever Clamping, Wear Resistant |
| Head Material, Shank Material | Heat-Treated Alloy Steel |
| Insert Clearance Angle | 7 Degrees |
| Insert Holding Type | P-Clamping |
| Insert Shape | 90 Degrees Rectangular |
| Insert Size | 19 |
| Insert Style | LNUX |
| Item | Indexable Boring Bar |
| Max. Bore Depth | 2.7550 in |
| Overall Length | 9.842 in |
| Shank Dia. | 55 mm |
| Shank Length | 7.0870 in |
| Toolholder Style | Railway Toolholder |
