| ANSI Code, ISO Number | NTK2R |
| Chip-Breaker | No |
| Clearance Angle | 15 Degrees |
| Coating Process | PVD |
| Corner Radius | 0.08mm |
| Country of Origin (subject to change) | United States |
| Cutting Application | Turning |
| Cutting Direction, Thread Direction | Right Hand |
| Features | Deformation Resistant |
| Finish - Machining | TiAlN |
| Grade, Manufacturer Grade | TN6010 |
| Hole Type | No Hole |
| Included Angle | 60 Degrees |
| Insert Holding Type | Top Clamp |
| Insert Shape, Product Family | Top Notch |
| Insert Size, Number of Cutting Edges | 2 |
| Insert Style | NT |
| Item | Threading Insert |
| Material - Machining | Carbide |
| Max. Thread Pitch | 44 |
| Measurement System | Metric |
| Min. Thread per Inch | 14 |
| Min. Thread Pitch | 1.00mm |
| Primary Material Application | Cast Iron, Nickel, Stainless Steel, Steel, Titanium |
| Primary Material Application ISO Code | K, M, P, S |
| Secondary Material Application | Aluminum, Brass, Bronze, Copper, Hardened Steel |
| Secondary Material Application ISO Code | H, N |
| Style | Partial Profile |
| Thickness | 5.56mm |
| Thread Height Difference | 2.50mm |
| Thread Pitch | 1.00mm to 2.00mm |
| Thread Profile Type | Partial |
| Thread Standard | UN |
| Thread Type | 60 Degree Partial |
| Threading Location | External, Internal |
