| ANSI Code, ISO Number | TCF0625R5SLR075B |
| Central Insert Style, Toolholder Style | TCF |
| Coolant Fed | Coolant Through |
| Country of Origin (subject to change) | Germany |
| Cutting Direction, Spiral Direction | Right Hand |
| Depth x Dia. Ratio, Ratio | 5xD |
| Diameter | 3/4" |
| Drilling Application | 45 Degrees Corner, Blind Hole, Chain, Convex, Cross Hole, Half Cylindrical, Inclined Entry, Inclined Exit |
| Flanged Shank | Yes |
| Flute Length | 3.8350 in |
| Flute Type | Slow Spiral |
| Item | Indexable Insert Drill |
| Max. Drilling Depth | 3.1480 in |
| Measurement System | Fractional Inch |
| Min. Drill Dia. | 5/8 in |
| Mounting Style | Screw Clamp |
| Number of Coolant Holes, Number of Inserts | 2 |
| Overall Length | 5.9611 in |
| Seat Size | B |
| Shank Dia. | 3/4 in |
| Shank Length | 1.9685 in |
| Shank Type - Machining | Round with Flat and Side Lock |
