| ANSI Code, ISO Number | TCF1469R3SLR150F |
| Central Insert Style, Toolholder Style | TCF |
| Coolant Fed | Coolant Through |
| Country of Origin (subject to change) | United States |
| Cutting Direction, Spiral Direction | Right Hand |
| Depth x Dia. Ratio, Ratio | 2.5xD |
| Diameter | 1-1/2" |
| Drilling Application | 45 Degrees Corner, Blind Hole, Chain, Convex, Cross Hole, Half Cylindrical, Inclined Entry, Inclined Exit, X-Offset |
| Flanged Shank | Yes |
| Flute Length | 143.90mm |
| Flute Type | Slow Spiral |
| Item | Indexable Insert Drill |
| Max. Drill Dia. | 38.31mm |
| Max. Drilling Depth | 113.30mm |
| Measurement System | Fractional Inch |
| Min. Drill Dia. | 37.31mm |
| Mounting Style | Screw Clamp |
| Number of Coolant Holes, Number of Inserts | 2 |
| Overall Length | 222.87mm |
| Seat Size | F |
| Shank Dia. | 1-1/2 in |
| Shank Length | 70.00mm |
| Shank Type - Machining | Round with Flat and Side Lock |
