Attributes
| Key ^ | Value |
|---|---|
| Adapter Type | Elbow and Straights |
| Body Material, Material | Stainless Steel |
| Country of Origin (subject to change) | China |
| End 1 Connection Type | Male |
| End 1 Hex | 0.688 |
| End 1 Hex (Metric) | 17.4752 |
| End 2 Connection Type | Female |
| Fitting Thread Size 1 | 3/8-18 |
| Fitting Thread Size 2 | 1/4-18 |
| Fitting Thread Type 1 | NPT |
| Fitting Thread Type 2 | NPT Swivel |
| Hex Size | 0.75 |
| Hex Size (mm) | 19.05 |
| Length, Overall Length | 1.3 |
| Overall Length (mm) | 33.02 |
| Standards | Stainless fittings meet SAE J514, SAE J1453, and SAE J1926 specifications. |
| Weight | 0.12 |
