Description:
Buy the Zemic B3G-N10-200-6YB from the trained experts at Scales Plus!
Attributes
| Key ^ | Value |
|---|---|
| Cable Color Code | Red = + Excitation, Black = - Excitation, Green = + Signal, White = - Signal |
| Cable Diameter | ????0.2in |
| Cable Length | 20 ft |
| Capacity | 200 lb |
| Compensated Temperature Range | 14??F to 104??F (-10??C to 40??C) |
| Construction | Stainless steel |
| Full Scale Output | 3 mV/V |
| Height | 2.4" |
| Hole Threading | 1/4-28UNF |
| Input Resistance | 430 (+/- 60) ohms |
| Insulation Resistance | 5000 megohms |
| IP Rating | IP67 |
| Length | 2" |
| Manufacturer | Zemic |
| Model | B3G-N10-200-6YB |
| NTEP | Yes |
| NTEP CC | 06-099A1 |
| Operating Temperature Range | -31?? F to 158?? F / -35??C to 70??C |
| Output Resistance | 351 (+/- 2) ohms |
| Rated Excitation | 5-12 VDC (maximum of 18 V) |
| Safe Overload | 150% capacity |
| Ultimate Overload | 300% capacity |
| Width | 0.59" |
