| 12VDC Battery Charger | 10A |
| Agency Compliance | CSA |
| Alarm Application | Indoor |
| Alarm Duration - Pumps, Primary Pump Duty Cycle | Continuous |
| Alarm Included, Handle | Yes |
| Alarm Output, Alarm Output - Pumps | Audible, Phone System, Visual, WiFi |
| Amps | 9.7 A |
| Amps - Back-Up | 10.00 |
| Amps - Pumps | 9.70 |
| Base Material | Polypropylene |
| Bearing Type | Ball |
| Body Material | Cast Iron (Primary); Plastic (Secondary) |
| Cord Length | 9 ft |
| Cord Length - Pumps | 9 ft. |
| Diameter | 18" |
| Discharge | 1-1/2 in M PVC Glue |
| Discharge Dia. | 1 1/2 in |
| Discharge Gender | Male |
| Discharge NPT | 1-1/2" F |
| Duty | Continuous (Primary), Intermittent (Secondary) |
| Duty Cycle | Continuous; Intermittent |
| Flow Rate @ 10 Ft. of Head | 34.0 gpm (Primary); 30.0 gpm (Secondary) |
| Flow Rate @ 15 Ft. of Head | 19.0 gpm (Primary); 20.0 gpm (Secondary) |
| Flow Rate @ 5 Ft. of Head | 43.0 gpm (Primary); 39.0 gpm (Secondary) |
| For Use With | Dewatering Systems |
| GPH of Water @ 0 Ft. of Head | 2700 (Primary), 2040 (Secondary) |
| GPH of Water @ 10 Ft. of Head | 2040 (Primary), 1800 (Secondary) |
| GPH of Water @ 15 Ft. of Head | 1140 (Primary), 1200 (Secondary) |
| GPH of Water @ 5 Ft. of Head | 2580 (Primary), 2340 (Secondary) |
| GPM of Water @ 10 Ft. of Head | 34 (Primary), 30 (Secondary) |
| GPM of Water @ 15 Ft. of Head | 19 (Primary), 20 (Secondary) |
| GPM of Water @ 20 Ft. of Head | 12 (Primary), 6 (Secondary) |
| GPM of Water @ 5 Ft. of Head | 43 (Primary), 39 (Secondary) |
| Height | 20-1/2" |
| HP | 3/10 (Primary); 1/3 (Secondary) |
| Hz, Primary Pump Hz | 60 |
| Impeller Material | Polypropylene (Primary) |
| Impeller Material - Pumps, Primary Pump Impeller Material | Glass Filled Polypropylene |
| Includes | Battery Charger, Check Valve, Battery Box, Mount, Controller with Internet Connection, Primary Pump |
| Input Phase AC, Primary Pump Phase | 1 |
| Item, Item - Sump Pumps | Sump/Battery Back-Up System |
| Length | 20" |
| Manufacturers Warranty Length | 3 yr |
| Max. Dia. Solids (In.) - Back-Up | 1/4 |
| Max. Diameter Solids | 1/2" |
| Max. Flow (GPH) - Pumps | 2500 |
| Max. Flow (GPH), Max. Flow (GPH) - Back-Up | 2340 |
| Max. Head | 19.0 ft (Primary); 22.0 ft (Secondary) |
| Max. Head (Ft.) - Back-Up | 22 |
| Max. Head - Pumps | 19 ft. |
| Max. Liquid Temp. | 130 Degrees F |
| Min. Sump Pit Dia. | 18 in |
| Motor RPM, Pump RPM | 1550 |
| Motor Type | Shaded Pole (Primary), Brush Type DC (Secondary) |
| Off Point | 2 in to 5 in |
| On Point | 7 1/4 in |
| Outlet | 1-1/2" NPT |
| Overall Height, Primary Pump Overall Height | 20 1/2 in |
| Primary Pump Amps | 9.7 |
| Primary Pump Body Material | Cast Iron |
| Primary Pump Flow Rate @ 10 Ft. of Head | 34.0 gpm |
| Primary Pump Flow Rate @ 15 Ft. of Head | 19.0 gpm |
| Primary Pump Flow Rate @ 5 Ft. of Head | 43.0 gpm |
| Primary Pump Maximum Head | 19 ft |
| Primary Pump Maximum Solids Diameter | 1/2 in |
| Primary Pump Rated Voltage | 120V AC |
| Primary Pump RPM | 1,550 |
| Primary Pump Shaft Seal Material | Buna-N |
| Primary Pump Width at Widest Point, Width at Widest Point | 11 in |
| Pump Body Material | Cast Iron (Primary), Plastic (Secondary) |
| Pump HP | 1/3 |
| RPM | 1,550 RPM |
| Secondary Pump Amps | 10 |
| Secondary Pump Body Material | Plastic |
| Secondary Pump Duty Cycle | Intermittent |
| Secondary Pump Flow Rate @ 10 Ft. of Head | 30.0 gpm |
| Secondary Pump Flow Rate @ 15 Ft. of Head | 20.0 gpm |
| Secondary Pump Flow Rate @ 5 Ft. of Head | 39.0 gpm |
| Secondary Pump HP | 1/3 hp |
| Secondary Pump Maximum Head | 22 ft |
| Secondary Pump Rated Voltage | 12V DC |
| Secondary Pump Shaft Seal Material | Ceramic |
| Shaft Seal Material - Pumps | Nitrile Rubber, Carbon, Ceramic |
| Switch Actuation | Vertical Float |
| Switch Type - Pumps | Float |
| Voltage - Back-Up, Voltage - Pumps | 12VDC |
| Width | 11" |
