| Caster Brake Included, Caster Temp. Range Available, Non-Marking | Yes |
| Caster Brake Type | Side Thumbscrew |
| Caster Core Material, Wheel Core Material | Cast Iron |
| Caster Frame Material, Frame Material | Steel |
| Caster Load Rating Range, Load Rating Range | Extra Super Duty |
| Caster Max. Temp. | 175 Degrees F |
| Caster Min. Temp. | -20 Degrees F |
| Caster Plate Hole Pattern, Plate Caster Bolt Hole Pattern | D |
| Caster Plate Size, Mounting Plate Size, Plate Size | 7-3/4" x 9-3/8" |
| Caster Plate Thickness | 1-3/16" |
| Caster Product Group | Kingpinless Caster with 4-Position Directional Lock and Brake |
| Caster Raceway, Swivel Raceway Type | Single Ball |
| Caster Sub-Type | Kingpinless Swivel |
| Caster Swivel Lock Type, Swivel Lock Type | 4-Position Directional Lock |
| Caster Temp. Range | -22 Degrees to 176 Degrees F |
| Caster Wheel Bearings | Roller |
| Caster Wheel Shape, Tread Shape | Standard |
| Caster Wheel/Tread Material, Wheel/Tread Material | Polyurethane |
| Core Color | Gray |
| Country of Origin (subject to change) | United Kingdom |
| Durometer | 95 Shore A |
| Frame Finish | Enamel |
| Inside Bolt Hole Spacing, Outside Bolt Hole Spacing | 4" x 7-3/4" |
| Item | Plate Caster |
| Load Rating | 9350 lb. |
| Mounting Bolt Dia. | 5/8" |
| Number of Wheels | 2 |
| Overall Height | 12-1/2" |
| Plate Thickness | 1.188" |
| Replacement Wheel | 5VF52 |
| Wheel Color | Tan |
| Wheel Dia. | 10" |
| Wheel Width | 3" |
