| Accuracy, Gauge Accuracy | +/-3-2-3% |
| Basic Gauge Case Material, Basic Gauge Lens Material | Plastic |
| Basic Gauge Sensor Material, Gauge Sensor Material | Bronze |
| Basic Gauge Socket Material, Gauge Socket Material | Brass |
| Basic Gauge Wetted Parts | Brass / Bronze |
| Calibration Certificate Included, Gauge Panel Mountable, Liquid Filled | No |
| Case Color, Color, Gauge Case Color | Black |
| Connection Location, Gauge Connection Location | Bottom |
| Connection Size | 1/4 in NPT |
| Country of Origin (subject to change) | China |
| Dial Size (In.) | 2-1/2 |
| For Use With | Air and Noncorrosive Fluids Such as Water and Oil in Pumps, Filters, Compressors, and Regulators |
| Gauge Application | Test |
| Gauge Case Material, Material | ABS plastic |
| Gauge Connection Size | 1/4 in |
| Gauge Connection Type | MNPT |
| Gauge Lens Material | Acrylic |
| Gauge Nominal Dial Size | 2 1/2 in |
| Gauge Primary Range Smallest Graduation | 20 |
| Gauge Primary Range Units | psi |
| Gauge Primary Range Values | 0 to 1000 |
| Gauge Secondary Range Units | kPa |
| Gauge Secondary Range Values | 0 to 7000 |
| Item, Pressure and Vacuum Gauge Type | Pressure Gauge |
| Max. Pressure (PSI) | 1000 |
| Operating Temp. Range | -40 Degrees to 150 Degrees F |
| Range | 0 to 1000 psi, 0 to 7000 kPa |
| Smallest Graduation | 20 psi |
