| Application | Platform Trucks, Warehouse Trucks, Material Handling Containers, Dollies, Waste Disposal Trucks, Floor Trucks, Shop Carts |
| Caster Brake Included | Yes |
| Caster Brake Type | Total Lock Brake |
| Caster Core Material | Aluminum |
| Caster Frame Material | Steel |
| Caster Load Rating Range | Medium-Duty |
| Caster Max. Temp. | 180 Degrees F |
| Caster Min. Temp. | -40 Degrees F |
| Caster Plate Hole Pattern | B |
| Caster Plate Size | 4" x 4-1/2" |
| Caster Plate Thickness | 1/4" |
| Caster Product Group | Swivel Caster with Total Lock |
| Caster Raceway | Double Ball |
| Caster Stem Type | No Stem/Plate Included |
| Caster Sub-Type | Swivel |
| Caster Swivel Lock Type | Total Lock |
| Caster Temp. Range | -40 Degrees to 180 Degrees F |
| Caster Temp. Range Available | Yes |
| Caster Wheel Bearings | Roller |
| Caster Wheel Shape | Standard |
| Caster Wheel/Tread Material | Polyurethane |
| Core Color | Silver |
| Country of Origin (subject to change) | United States |
| Durometer | 55 Shore D |
| Extended Lead | No |
| Frame Finish | Zinc Chromate |
| Frame Material | Steel |
| Includes | Top Grease Seal |
| Inside Bolt Hole Spacing | 3 in x 3 in |
| Item | Plate Caster |
| Load Rating | 1200 lb |
| Load Rating Range | Medium |
| Mounting Bolt Dia. | 3/8 in |
| Mounting Plate Size | 4 in x 4 1/2 in |
| Non-Marking | No |
| Number of Wheels | 1 |
| Outside Bolt Hole Spacing | 2 5/8 in x 3 5/8 in |
| Overall Height | 7-1/2" |
| Plate Caster Bolt Hole Pattern | B |
| Plate Size | 4" x 4-1/2" |
| Plate Thickness | 1/4" |
| Replacement Wheel | Mfr. No. PD0620112BG |
| Stem Dia. | No Stem |
| Swivel Lock Type | Total Lock |
| Swivel Raceway Type | Double Ball |
| Thread Guards | No |
| Tread Shape | Standard |
| Wheel Color | Blue |
| Wheel Core Material | Aluminum |
| Wheel Dia. | 6 in |
| Wheel Width | 2 in |
| Wheel/Tread Material | Polyurethane |
