Description:
Blind Flange, Flat, 3/4 in Nominal Pipe Size, Blind, 3 7/8 in Flange Outside Diameter, 7/16 in Flange Thickness, Schedule 80, Class Class 150, For Pipe Schedule 80, CPVC, 150 psi Maximum Operating Pressure, 176 Degrees F, Number of Bolt Holes 4, 2 3/4 in Bolt Circle Diameter, 9/16 in Bolt Hole Diameter, 1/2 in Overall Length, Gray
Attributes
| Key ^ | Value |
|---|---|
| Basic Pipe Fitting Material | Plastic |
| Basic Pipe Fitting Shape, Item, Specific Fitting Shape, Specific Pipe Fitting Shape | Flange |
| Bolt Circle Diameter | 2 3/4 in |
| Bolt Hole Diameter | 9/16 in |
| Color | Gray |
| Fitting Connection Type, Pipe Fitting Connection Type | Blind |
| Fitting Pipe Size, Nominal Pipe Size, Pipe Size | 3/4 in |
| Fitting Schedule/Class, Pipe Fitting Schedule/Class | Schedule 80 |
| Flange Outside Diameter | 3 7/8 in |
| Max. Temp. | 176 Degrees F |
| Number of Holes | 4 |
| Outside Dia. | 3-7/8" |
| Overall Length | 1/2 in |
| Pipe Fitting Material | CPVC |
| Pipe Size (Fittings), Pipe Size - Pipe Fitting | 3/4" |
| Standards | NSF |
