| Application | Water |
| Autoclavable, Peristaltic Pump Compatible | No |
| Bend Radius, Tube Bend Radius | 5 in |
| Beverage, Food, and Water Compatibility, Food and Beverage Compatibility | Potable Water |
| Clarity | Opaque |
| Color, Tube Color | Orange |
| Country of Origin (subject to change) | United States |
| Features | Exterior Oxygen Diffusion Barrier Limits Oxygen Permeation |
| Fitting Compatibility | Push-to-Connect, Twist Lock |
| Flexibility | Flexible |
| Green Certification or Other Recognition | NSF(R) Certified (Sustainability or Environmental Standard) |
| Inside Dia., Inside Diameter, PEX Copper Tube Size, PEX Size | 1/2 in |
| Item | Tubing |
| Jacket Color, Jacket Material | No Jacket |
| Material Trade Name, Material Trade Number, Petroleum Product Compatibility | Not Applicable |
| Max. Pressure, Maximum Operating Pressure | 160 psi |
| Maximum Operating Temperature | 200 Degrees F |
| Minimum Operating Temperature | 0 Degrees F |
| Outside Dia., Outside Diameter | 5/8 in |
| Overall Length, Tube Length | 300 ft |
| PEX Shape, Tube Form | Coil |
| PEX Type | PEX-C |
| Reinforcement | Not Reinforced |
| Resistance Properties | Corrosion Resistant |
| Standards | ASTM F876, ASTM F877, AWWA C904, CSA B137.5, NSF 14, NSF 61, P171 |
| Stripe Color | No Stripe |
| System of Measurement | Inch |
| Temp. Range | 0 Degrees F to 200 Degrees F |
| Tube Material | PEX |
| Tubing Material | PEX (Cross-linked Polyethylene) |
| Wall Thickness | 1/16 in |
