Panasonic Electronic Components ECA-1HM101B Aluminum Electrolytic Capacitor, 100uF, 50V, 20%, Radial

Panasonic Electronic Components ECA-1HM101B Aluminum Electrolytic Capacitor, 100uF, 50V, 20%, Radialzoom

Attributes

Key Value
Alternate Part No.667-ECA-1HM101B
ApplicationsGeneral Purpose
Base Product NumberECA-1HM
BrandPanasonic
Capacitance100 ?F, 100 uF
Capacitance Range100 to 999 uF
Case Diameter8 mm
Case Length11.5 mm
Case SizeDia. 0.315 x L 0.453 in.
CategoryCapacitors
ConfigurationRadial ; Can
DescriptionCAP ALUM 100UF 20% 50V .
Detailed Description100 ?F 50 V Aluminum El.
Digi-Key Part NumberP10397TB-ND - Tape & Bo.
Dimensions8 mm Dia. x 11.5 mm L, .
Dissipation Factor DF0.12
Element MaterialAluminum Electrolytic
ESR (Equivalent Series .-
Height - Seated (Max)0.492" (12.50mm)
Lead Diameter0.6 mm
Lead Spacing5 mm, 0.197 In. (5.00 m.
Life2000 Hours
Lifetime @ Temp.2000 Hrs @ 85?C
Load Life2000 h
ManufacturerPanasonic Electronic Co.
Manufacturer Part No.ECA-1HM101B
Manufacturer Product Nu.ECA-1HM101B
Manufacturer Standard L.34 Weeks
Maximum Operating Tempe.+ 85 C, 85 C
MfrPanasonic Electronic Co.
Minimum Operating Tempe.-40 C
Mounting TypeThrough Hole, PCB Mount
Operating Temperature-40?C ~ 85?C
PackageTape & Box (TB)
Package / CaseRadial, Can
PackagingAmmo Pack, Tape & Box (.
PolarizationPolar
ProductGeneral Purpose Electro.
Product CategoryAluminium Electrolytic .
Product StatusActive
Ratings-
Ripple Current250 mA
Ripple Current @ High F.425 mA @ 10 kHz
Ripple Current @ Low Fr.250 mA @ 120 Hz
SeriesM Series, M-A, M
Size / Dimension0.315" Dia (8.00mm)
Surface Mount Land Size-
TerminationThrough Hole
Termination StyleRadial
Tolerance20% %, ?20%, 20 %
Voltage - Rated50 V
Voltage Rating50 VDC
Voltage Rating DC50 V

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
Future Electronics40288050.075100048000Panasonic0.075 @ 1000
thumbzoomTMEECA1HM101B0.10320001000PANASONIC0.103 @ 2000
thumbzoomDigi-Key2684820.105721000175000Panasonic Electronic Components0.10572 @ 1000
Onlinecomponents.comECA-1HM101B0.13515464PANASONIC0.135 @ 5
us.rs-online.com702558670.2079910005Panasonic Electronic Components0.20799 @ 1000
thumbzoomNewark47AC44420.372129041PANASONIC0.372 @ 5
thumbzoomswatee.comECA-1HM101B0.6115932Panasonic0.61 @ 5
MCM ElectronicsP-ECA1HM101B1.7915Panasonic1.79 @ 5
