- mpnB0090NZH4M
- brandname: Red Lion
- manufacturername: Red Lion
Red Lion C48C Dual Preset 1/16 DIN Counter Digital Panel Meter with Relay Output, 6 Digit Reflective LCD Display, 85-250 VAC Input Voltage, 50/60 Hz
- Brand: Red Lion
- PartNumber: C48CD002
- Model: C48CD
- Size: Relay Output, Reflective Backlight
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: Red Lion Controls Inc
- Label: Red Lion Controls Inc
Attributes
| Key | Value |
|---|
| Approvals | CE, cUL, UL |
| Backlight | No |
| Batch Counting | Yes |
| Brand | Red Lion |
| Catalog Number | C48CD002 |
| Category | Industrial Automation a. |
| Communications | None |
| Connection Type | Screw Terminal |
| Count Mode | Bidirectional, Quadratu. |
| Count Rate | Multiple |
| Count Speed (Hz) | 50,000 Hz |
| Country of Origin (subj. | United States |
| Description | COUNTER LCD 6 CHAR 85-2. |
| Detailed Description | Preset 85 ~ 250VAC Pane. |
| Digi-Key Part Number | RLC209-ND |
| Display | LCD - 2 Lines |
| Display Characters - He. | 0.300" (7.62mm), 0.200". |
| Display Digit Height | 5.08 to 7.62 mm |
| Display Type | LCD, LCD - Black Charac. |
| Family Series | Red Lion Counters, C48C. |
| Function | Batch Counter, Dual Cou. |
| Gross Weight | 0.82 lbs |
| Ingress Protection | IP66 - Dust Tight, Wate. |
| Input Type | No Voltage, Voltage, Si. |
| IP Rating | IP65 |
| Item | Counter |
| Item Number | C48CD002 |
| Item Type | Panel Meters - Counter |
| Lockout | No |
| Manufacturer | Red Lion Controls, Red . |
| Manufacturer Part Number | C48CD002 |
| Manufacturer Product Nu. | C48CD002 |
| Manufacturer Standard L. | 2 Weeks |
| Measuring Range | -9999999 to 9999999 hr |
| Memory | Nonvolatile RAM |
| Mfr | Red Lion Controls |
| Min. On/Off Pulse | 10 msec |
| Mounting | Panel, DIN - 1/16 |
| Mounting Type | Panel Mount, DIN Rail M. |
| NEMA Rating | NEMA 4x |
| Net Weight | 0.36 lbs |
| Nominal Supply Voltage | 12 VDC, 120 VAC, 208 VA. |
| Number of Characters Pe. | 6, 6 |
| Number of Digits | 6 |
| Number of Presets | 2 |
| Operating Mode | Up, Down, Quadrature |
| Operating Temperature | 0?C ~ 50?C |
| Output Type | Relay (2), (2) Relay |
| Package | Box |
| Panel Cutout Dimensions | Square - 45.00mm x 45.0. |
| Prescaling Range | 0.00001 to 9.99999 |
| Preset | 2 |
| Product Series | C48CD |
| Product Status | Active |
| Product Type | Preset Counter |
| Reset | Auto, Electric, Front P. |
| Reset Type | Front Panel Push Button. |
| Scale Calibrator | 0.00001-9.99999 Multipl. |
| Scaler | Yes |
| Sensor Power | 12 VDC |
| Series | C48C, C48C Series |
| Supply Voltage | 11-14 VDC, 85-250 VAC, . |
| Temp Range (C) | 0-50 ?C |
| Termination | Screw Terminals |
| Termination Style | Screw Terminal |
| Time Format | - |
| Type | Preset, Electronic |
| Voltage - Supply | 85 ~ 250VAC |
| Weight | 0.375, 0.375 lb (170.1 . |
| Weight UOM | Pounds |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| Hotenda | H2267165 | 193.78 | 1 | 5 | | Red Lion Controls | | 193.78 @ 1 |
 | Carlton Bates Company | 78073610072 | 236.17 | 1 | In Stock | | RED LION CONTROLS | | 236.17 @ 1 |
| steinerelectric.com | 344074 | 237.0 | 1 | In Stock | | redlion | | 237.0 @ 1 |
 | Radwell | C48CD002 | 260.0 | 1 | 3 | | RED LION CONTROLS | | 260.0 @ 1 |
 | sustainablesupply.com | C1159746 | 282.4 | 1 | In Stock | | Red Lion | 0.85 | 282.4 @ 1 |
 | Newark | 63R2826 | 291.0 | 1 | 5 | | RED LION CONTROLS | | 291.0 @ 1 |
 | Walker Industrial | C48CD002 | 291.0 | 1 | In Stock | 17 | Red Lion Controls | | 291.0 @ 1 |
 | MRO Supply | 286375 | 291.0 | 1 | In Stock | | Red Lion Controls | | 291.0 @ 1 |
 | Digi-Key | 3595232 | 295.38 | 1 | In Stock | | Red Lion Controls | 0.375 | 295.38 @ 1 |
 | crescentelectric.com | 762987 | 307.56 | 1 | In Stock | | Red Lion | | 307.56 @ 1 |
 | Galco | C48CD002-RDL | 319.16 | 1 | In Stock | | Red Lion | 0.82 | 319.16 @ 1 |
| us.rs-online.com | 70030588 | 331.45 | 1 | 3 | | Red Lion Controls | | 331.45 @ 1 |
 | Zoro | G204392816 | 338.15 | 1 | In Stock | | Red Lion Controls | 0.81 | 338.15 @ 1 |
| RS Delivers | 282-6438 | 345.78 | 1 | 5 | | Red Lion | | 345.78 @ 1 |
