BandB Manufacturing 36XL037-6S4

B01KZ29NM8

BandB Manufacturing 36XL037-6S4 Timing Pulley, 36 Teeth, XL Pitch for 0.375" Wide Belts, 1 Flange and Hub Serves as Second Flange, 0.313" Bore

BandB Manufacturing 36XL037-6S4 Timing Pulley, 36 Teeth, XL Pitch for 0.375" Wide Belts, 1 Flange and Hub Serves as Second Flange, 0.313" Borezoom

Attributes

Key Value
Bore (in)5/16 Inch Finished Bore
Bore Diameter5/16 in
Bore TypeFinished, Minimum Plain.
Description:36XL037-6S4, Timing Pul.
Face Width0.563 in
Face Width (in)0.563
FinishBlack Oxide
For Belt Width (in)0.375
Hub Diameter1-1/2 in
Hub Diameter (in)1.500
ManufacturerB & B Manufacturing
MaterialSteel
Max. Bore (in)1.25
MFG Part #:36XL037-6S4
Min. Bore (in)0.3125
MOQ1
Number of Grooves36
Outside Diameter2.272 in
Outside Diameter (in)2.272
Overall Length1 in
Overall Length (in)1.000
Part Number Cross Refer.1430842, 36XLB037S, 36X.
Pitch0.2 in
Pitch Diameter2.292 in
Pitch Diameter (in)2.292
Product Number36XL037-6S4
Set Screw2 x 1/4-20 @ 90
Suitable For Use With3/8 in W Belt
Supplier:B & B Manufacturing
Teeth36
Tooth StyleXL
TypeType 6, 6
Unit SystemInch
UPC:195057623316
Weight (lb)0.84

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomBandB36XL037-6S448.5924124B & B Manufacturing48.5924 @ 1
kscdirect.comBBM 36XL037-6S449.771In StockB & B Manufacturing49.77 @ 1
