Martin TC860

B004BDO5UI

Martin TC860 Spur Gear, 20? Pressure Angle, Cast Iron, Inch, 8 Pitch, 1" Bore, 7.75" OD, 1.500" Face Width, 60 Teeth

Martin TC860 Spur Gear, 20? Pressure Angle, Cast Iron, Inch, 8 Pitch, 1" Bore, 7.75" OD, 1.500" Face Width, 60 Teethzoom

Attributes

Key Value
Bore Diameter1 in ; 25.4 mm
bore diameter:1 to 1-7/8 in
Bore TypeReboreable
bore type:Rough Stock
Class6
Diametral Pitch8
diametral pitch:8
External Length1" (25.4mm)
Face Width (In.)1.5
face width:1-1/2 in
gear construction:Webbed with Lightening .
Gear TypeB2
Hub Dia. (In.)3
hub diameter:3 in
Hub Outside Diameter3" (76.2mm)
Hub Projection (In.)1
hub projection:1 in
Hub StyleB
hub type:Hub w/ No Screw
Length through Bore2.5
Length Through Bore2.5" (63.5mm)
MaterialCast Iron
material:Cast Iron
Max. Bore1.875
Maximum Bore Diameter1.875" (47.6mm)
Min. Bore1
Number of Teeth60
Number Of Teeth60
number of teeth:60
Outer Diameter7.75" (196.9mm)
Outside Dia7.750"
Outside Dia. (In.)7.75
outside diameter:7-3/4 in
overall width:2-1/2 in
Pitch8
Pitch Dia. (In.)7.5
Pitch Diameter7.5" (190.5mm)
pitch diameter:7-1/2 in
Pressure Angle20 Degrees PA
Pressure Angle (Deg.)20
pressure angle:20
standards met:ANSI Standard B15.1
Storage Height2.5
Storage Length7.75
Storage Width7.75
StyleB
UPC Code697950294032
Weight12 lbs. (5.4 kg), 12
Width0 in

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomindustrialzone.comTC860233.631In StockMartin1.0233.63 @ 1
thumbzoommotionindustries.com00371988256.31In StockMartin256.3 @ 1
us.rs-online.com72332871261.991In StockMartin Sprocket & Gear12.0261.99 @ 1
thumbzoomcbtcompany.comTC860264.331In StockMartin Sprocket & Gear264.33 @ 1
thumbzoomMRO Supply251555275.21In StockMartin Sprocket275.2 @ 1
thumbzoomZoroG3360991339.681In Stock14Martin Sprocket & Gear12.0339.68 @ 1
thumbzoomPurvisTC860342.621In StockMartin342.62 @ 1
