Phoenix 1719118

B00HKTHTK8

Pluggable Terminal Blocks TVMSTB 2.5/4STF5.08 4P DUAL ENTRY FLNG

Pluggable Terminal Blocks TVMSTB 2.5/4STF5.08 4P DUAL ENTRY FLNGzoom

Attributes

Key Value
Alternate Mfr Part Numb.TVMSTB 2 5/ 4-STF-5 08
Alternate Part No.651-1719118
ApprovalsVDE Gutachten mit Ferti.
BrandPhoenix Contact
CategoryConnectors, Interconnec.
ColorGreen
Connection MethodScrew
Contact Material-
Contact Mating FinishTin
Contact PlatingTin
Contact Tail Length-
Current - IEC12A
Current - UL10A
Current Rating12 A
Family NameCOMBI Plug Family
FeaturesMating Flange, Retentio.
Header Orientation-
Housing MaterialPolyamide (PA), Nylon
Ingress Protection-
Insulation Height1.016"" (25.81mm)
ManufacturerPhoenix Contact
Manufacturer Part No.1719118
Material Flammability R.UL94 V-0
MfrPhoenix Contact
Mounting TypeFree Hanging (In-Line),.
Number of Levels1 (Mate), 2 (Input)
Number of Positions4, 4 Position
Number of Rows1 (Mate), 2 (Input)
Operating Temperature-
PackageBulk
Part # AliasesTVMSTB_2,5/_4-STF-5,08 .
Part StatusActive
Pitch0.200"" (5.08mm), 0.200.
Plug Wire Entry90? and 270?
Positions Per Level4 (Mate), 8 (Input)
Primary TypeWire to Board
ProductPlugs
Product CategoryPluggable Terminal Bloc.
Screw SizeM3
SeriesTVMSTB, COMBICON TVMSTB
Special FeaturesMating Flange ; Retenti.
TerminationSocket
Termination StyleScrew - Rising Cage Cla.
Torque - Screw0.5-0.6 Nm (4.4-5.3 Lb-.
TradenameCOMBICON Control
TypePlug, Female Sockets
Unit Weight14.370 g
UPC Code4046356156325
Voltage - IEC630V
Voltage - UL300V
Voltage Rating250 V
Wire Entry90? and 270?
Wire Gauge or Range - A.12-30 AWG
Wire Gauge or Range - m.0.2-2.5mm?
Wire Gauge Range24-12
Wire Size12-30 AWG
Wire Strip Length7mm
Wire Termination TypeScrew - Clamping Yoke (.

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
electricautomationnetwork.comTVMSTB 2,5/ 4-STF-5,085.771In StockPHOENIX_CONTACT5.77 @ 1
Radwell17191188.350In StockPHOENIX CONTACT8.3 @ 50
industrialautomationparts.comAE-0061679.341In StockPhoenix Contact9.34 @ 1
Digi-Key36062109.3650In StockPhoenix Contact9.36 @ 50
MRO Stop75303288010.481In StockPhoenix Contact10.48 @ 1
Airline HydraulicsPHOENIX 171911810.891In StockPhoenix Contact10.89 @ 1
thumbzoomswatee.com171911811.93128Phoenix Contact11.93 @ 1
