- mpnF724-30-B5-G
- brandname: Boston Gear
- manufacturername: Boston Gear
Speed Reducer, C-Face, 56C, 30:1
- Brand: Boston Gear
- PartNumber: F724-30-B5-G
- Model: F724-30-B5-G
- PackageQuantity: 1
- Binding: Misc.
- Manufacturer: BOSTON GEAR
- Label: BOSTON GEAR
Attributes
| Key | Value |
|---|
| Base | Optional |
| Bearings | Tapered Roller |
| Bore Dia. | 1-1/8", 5/8" |
| Brand | Boston Gear |
| Color | Grey |
| Country of Origin (subj. | United States |
| Current Stock | 3 |
| Dimension U | 1 1/8 in |
| Duty | Standard |
| Finish | Powdered Epoxy Paint |
| Frame | 56c |
| Gear Material | Hardened and Ground Ste. |
| Gear Type | Worm |
| Housing Material | Cast iron |
| Input RPM | 1750 rpm, 1750 |
| International Shipping | No |
| Item | Speed Reducer |
| Lubrication | Klubersynth UH1 6-460 |
| Max. Input HP | 1, 1 hp |
| Max. Output Torque | 832 in-lb, 832 in.-lb. |
| Mounting | Any Position |
| Mpn | F724-30-B5-G |
| Nominal Output rpm | 58.3 rpm |
| Nominal Output RPM | 58, 58 RPM |
| Nominal Ratio | 30:1 |
| Number of Stages | 1 |
| Output Shaft Dia. | 1 1/8 in |
| Output Shaft Height | 2 1/2 in |
| Output Torque @ 1 HP | 624 in-lb, 624 in-lbs |
| Output Torque @ 1.5 HP | 832 in-lbs, 832 in-lb |
| Output Torque @ 1/40 HP | 3600 in.-lb. |
| Overall Length | 10.18" |
| Overhung Load | 900 lb, 900 lb. |
| Pinion Material | Hardened Steel |
| Prop 65 | WARNING: Cancer and Rep. |
| Reducer Model No. | F724-30-B5-G |
| Rotation | Forward/Reversible |
| Seal Type | Double Lip |
| Shaft Orientation | Right Angle |
| Single/Double Output/Un. | Single Output |
| SKU | ZO-G1515455 |
| Solid/Hollow Output Sha. | Solid |
| Speed Reducer Type | C-Face |
| Standards | AGMA; ISO 9001:2015, AG. |
| SubCategory | Power Transmission |
| UPC | 781711520024 |
| Worm Center Distance | 2.38 in, 2.38" |
| Worm Gear Material | Bronze |
All Prices
| Img | Seller | Supplier SKU | Min Price | MOQ | In Stock | Lead Time | Brand | Weight | Preferred Tier |
|---|
| motionindustries.com | 01118068 | 659.72 | 1 | In Stock | | Boston Gear (Altra) | | 659.72 @ 1 |
 | Zoro | G1515455 | 773.37 | 1 | In Stock | | Boston Gear | 31.4 | 773.37 @ 1 |
 | MRO Supply | 42703 | 936.84 | 1 | In Stock | | Boston Gear | | 936.84 @ 1 |
 | simsupply.com | ZO-G1515455 | 1059.19 | 1 | 3 | | Boston Gear | | 1059.19 @ 1 |
| cbtcompany.com | F724-30-B5-G | 1064.83 | 1 | In Stock | | Boston Gear | | 1064.83 @ 1 |
| AmazonTP | B01IPGA8OS | 1101.84 | 1 | In Stock | 10 | Boston Gear | | 1101.84 @ 1 |
 | AmazonSC | B01IPGA8OS | 1114.07 | 1 | In Stock | | Boston Gear | | 1114.07 @ 1 |
| grainger.ca | WWG1L332 | 1311.40079692 | 1 | In Stock | | BOSTON GEAR | 31.4 | 1311.40079692 @ 1 |
 | Raptor Supplies | AB2BYD | 1554.122115 | 1 | In Stock | | BOSTON GEAR | | 1554.122115 @ 1 |
 | sustainablesupply.com | C1660574 | 1692.83 | 1 | In Stock | | Boston Gear | 31.4 | 1692.83 @ 1 |
