Tritan 50BS40 X 1

B00VI55PQK

TRITAN 50BS40 X 1 Finished Bore B-Hub Sprocket, 40 Teeth, 5/8" Pitch, 1" Finished Bore

TRITAN 50BS40 X 1 Finished Bore B-Hub Sprocket, 40 Teeth, 5/8" Pitch, 1" Finished Borezoom

Attributes

Key Value
ANSI Sprocket Number50
Bore Dia. (In.)1
Bore Dia. - Sprockets1 Inch
Bore Diameter1 in
Bore TypeFinished Bore with Keyw.
BrandTritan
Chain Number50
ColorBlack Oxide
Country of Origin (subj.China
Current Stock3
FinishBlack Oxide
For Chain Number50
For Chain Pitch5/8 in
For Number of StrandsSingle
For Use WithRoller Chain
Hub Dia.3.25 in
Hub Dia. (In.)3-1/4
Hub Diameter3 1/4 in
Hub Projection1 in
Hub TypeOne Side
IncludesStandard Keyway and (2).
Industry Chain Pitch5/8 in
Industry Chain Size50
International ShippingNo
ItemSprocket
Item - Roller Chain Spr.Roller Chain Sprocket
Keyseat Size (In.)1/4 x 1/8
Keyway Depth1/8 in
Keyway Size1/4 in x 1/8 in
Keyway Width1/4 in
Lead TimeExpected to ship in 1-2.
Length through Bore1 1/4 in
Length through Bore (In.1-1/4
MaterialSteel
Material - SprocketsForged 1045 Alloy Steel
Maximum Bore Diameter1 in
Mpn50BS40 X 1
Number of Chain RowsSingle
Number of Set Screws2
Number of Teeth40
Number of Teeth - Sproc.40
Outside Dia.8.307 in
Outside Dia. (In.)8.307
Outside Diameter8 in
Pitch5/8"
Pitch Dia.0.625 in
Pitch Dia. (In.)0.625
Pitch Diameter7.966 in
Set Screw Dia. (In.)5/16
Set Screw Hole Dia.0.313 in
Set Screw LocationSetscrews are Placed Ov.
Setscrew LocationOne Setscrew Over The K.
SKUZO-G0028695
Sprocket Bore TypeFixed Bore
Sprocket Hub TypeB Hub Type
StandardsANSI B29.1, BIS
SubCategoryPower Transmission
Teeth Heat TreatmentNot Hardened
Temp. Range (F)-50 to +500? F
Tooth Width0.343 in
TypeFinished Bore
UPC888569101297
Width Across Tooth SetsNot Applicable

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomAmazonB00VI55PQK59.781In StockTritan59.78 @ 1
thumbzoomZoroG002869568.491In StockTritan6.9368.49 @ 1
thumbzoomsimsupply.comZO-G002869587.5513Tritan87.55 @ 1
thumbzoomRaptor SuppliesAH6UJY157.8368611In StockTRITAN157.836861 @ 1
