Lovejoy 68514424515

B013T0OK9O

Lovejoy 68514424515 LF Series LF 140 Flange Hub, 1.18" Rough Stock Bore, 3.15" Length Through Bore, 4.92" OD

Lovejoy 68514424515 LF Series LF 140 Flange Hub, 1.18" Rough Stock Bore, 3.15" Length Through Bore, 4.92" ODzoom

Attributes

Key Value
Allowable Continuous Vi.6200.00 in-lb
Bore TypeRough Stock Bore
ColorMetallic
Coupling SizeLF140
Cubic in ches330.30144 in3
Description:LF140-HUB FLNG-1.18 RSB;
Dimension FD6.300 in (160.02 mm)
Dimension FOD10.240 in
Dynamic Torsional Stiff.354000.00 in-lb /rad
Hub Diameter4.920 in (125.00 mm)
Length thru Bore3.150 in (80.00 mm)
ManufacturerLOVEJOY INC
Max. Angular Misalignme.2.00 ?
Max. Bore (Dimensions I.4.250 in (107.95 mm)
Max. Parallel Misalignm.0.080 in (2.00 mm)
Max. Speed3600.00 rpm
MFG Part #:68514424515
Min. Bore (Dimensions I.1.190 in (30.00 mm)
Nominal Torque15000.00 in-lb
Operating Temperature R.-40 to 194 ?F
Rough Stock Bore Size1.180 in
Securing Torque for Mou.43400.00 in-lb
Shore Hardness60A
Speed3600.00 rpm
Static Angular Stiffness336.00 in-lb /deg
Static Axial Stiffness3700.00 lb/in
Static Radial Stiffness13100.00 lb/in
StyleFlange
Supplier:LOVEJOY INC
Thread (Dimension T)M20
TypeTorsional
UPC:685144245151
Weight37.00 lb
Wind-Up Angle at Max. T.7.50 ?
Wind-Up Angle at Nomina.3.00 ?

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomMegadepot685144245151138.01In StockLovejoy37.01138.0 @ 1
thumbzoomheavydutydepot.com685144245151138.01In StockLovejoy1138.0 @ 1
thumbzoomusmegastore.com685144245151167.01In StockLovejoy37.01167.0 @ 1
AmazonB013T0OK9O1204.471In StockLovejoy1204.47 @ 1
kscdirect.comLOV 685144245151462.61In StockLOVEJOY INC1462.6 @ 1
thumbzoommidwestapplianceparts.com68514424515-LJ-P1652.161In StockLovejoy1652.16 @ 1
Airline HydraulicsLOVEJOY 685144245152285.991In StockLOVEJOY2285.99 @ 1
