Panasonic FV-0511VHL1 WhisperWarm DC Bathroom Fan with Light and Heater - Simplified Ventilation and Heat - 50-80-110 CFM
- Brand: Panasonic
- PartNumber: FV-0511VHL1
- Model: FV-0511VHL1
- Color: White
- Size: Large
- PackageQuantity: 1
- Binding: Kitchen
- Manufacturer: Panasonic
- Label: Panasonic
Attributes
| Key | Value |
|---|
| AMP | 0.1, 0.15, 0.18, 0.25, . |
| Amps | 0.1/0.15/0.25 |
| Blower Wheel Curve | Forward |
| Brand | Panasonic Eco Products |
| Bulb Type | LED |
| Catalog Number | FV-0511VHL1 |
| CEC Compliant | For Sale in CA |
| CFM | 110 |
| CFM @ 0.100-In. SP | 50/80/110CFM |
| Collection | WhisperWarm? DC? |
| Color Finish | White |
| Country of Origin (subj. | Mexico |
| Depth | 7-1/2 in |
| Dimmable | Yes |
| Discharge | Vertical |
| Discharge Direction | Vertical |
| Duct Dia. | 4 or 6 in |
| Duct Diameter | 4 in |
| Duct Shape | Round |
| Duct Size | 6 in |
| Energy Star Compliant | Yes |
| ETL Listed | No |
| Exhaust Airflow @ 0.100. | 110 cfm |
| Exhaust Airflow @ 0.250. | 52 cfm, 81 cfm, 111 cfm |
| For Cut-Out Length | 16 in |
| For Cut-Out Width | 10 1/4 in |
| Frequency | 60 Hz |
| Full Load Current | 0.1 A, 0.15 A, 0.18 A, . |
| Green | Energy Star, Yes |
| Grille Length | 18 1/4 in |
| Grille Material | Polypropylene |
| Grille Width | 13 1/4 in |
| Heat Watts | 1600 |
| Heater | Yes |
| Heater Type | Heating Coil |
| Heater Wattage | 1,600 W |
| Height | 7-1/2 in |
| Housing Height | 7 1/2 in |
| Housing Length | 16 in |
| Housing Material | ZAM-Zinc-Aluminum-Magne. |
| Housing Width | 10 1/4 in |
| Humidity Sensing | No |
| Hz | 60 Hz |
| Includes | Hardware & Flex-Z Fast . |
| Includes Grill | Yes |
| Includes Light Bulbs | Yes |
| Installation Type | Ceiling Mount, Wall Mou. |
| Item | Fan/Heater Combination |
| Length | 16 in |
| Light Color Temperature | Warm White |
| Lighted | Yes |
| Manufacturer | Panasonic Eco Products |
| Material | Aluminum, Magnesium, Zi. |
| Maximum Noise Level | 1.5 sones |
| Motion Sensing | No |
| Motor Speed | 654 RPM, 745 RPM, 885 R. |
| Nameplate Voltage | 120V AC |
| Night Light Technology | LED |
| Night Light Wattage | 0.2 W |
| Night-Light | Yes |
| Noise Level @ 0.100 in . | 0.7 sones |
| Noise Level @ 0.250 in . | 1.5 sones |
| Nominal RPM | 654/745/885 RPM |
| Number of Primary Lights | 1 |
| Number of Speeds | 3 |
| Overall Depth | 10 1/4 in |
| Overall Height | 7 1/2 in |
| Overall HxWxD | 7 1/2 in x 16 in x 10 1. |
| Overall Width | 16 in |
| Phase | 1 |
| Primary Light Wattage | 10 W |
| Primary Lighting Techno. | LED |
| Profile | Medium |
| Profile Height Family | Low |
| Profile Width Family | Single-Wide |
| Promotion Restriction | Not eligible for promot. |
| Requires | Minimum 20 Amp Dedicate. |
| RPM | 1265 |
| Sensor Type | None |
| Sones | 0.7 |
| Sones @ 0.100-In. SP @ . | Less Than0.3/ Less Than. |
| Standards | cUL Listed, HVI Certifi. |
| UL Listed | Yes |
| UPC | 885170374188 |
| Vent Design | Ducted |
| Voltage | 120V AC |
| Volts | 120V |
| Watts | 4.7/7.4/12.4, 10.6 |
| Width | 6 in |
