Tritan 60BS18H X 1 5/8

B00VI592ZA

TRITAN 60BS18H X 1 5/8 Finished Bore B-Hub Sprocket, 18 Teeth, 3/4" Pitch, 1-5/8" Finished Bore

TRITAN 60BS18H X 1 5/8 Finished Bore B-Hub Sprocket, 18 Teeth, 3/4" Pitch, 1-5/8" Finished Borezoom

Attributes

Key Value
ANSI Sprocket Number60
Bore Dia. (In.)1-5/8
Bore Dia. - Sprockets1 5/8 in
Bore Diameter1 5/8 in
Bore TypeFixed
BrandTritan
Chain Number60
ColorBlack Oxide
Country of Origin (subj.China
FinishBlack Oxide
For Chain Number60
For Chain Pitch3/4 in
For Number of StrandsSingle
For Use WithRoller Chain
Hub Dia.3.5 in
Hub Dia. (In.)3-1/2
Hub Diameter3 1/2 in
Hub Projection1 in
Hub TypeOne Side
IncludesStandard Keyway and (2).
Industry Chain Pitch3/4 in
Industry Chain Size60
International ShippingNo
ItemSprocket
Item - Roller Chain Spr.Roller Chain Sprocket
Keyseat Size (In.)3/8 x 3/16
Keyway Depth3/16 in
Keyway Size3/8 in x 3/16 in
Keyway Width3/8 in
Length through Bore1 1/4 in
Length through Bore (In.1-1/4
MaterialSteel
Material - SprocketsSteel
Maximum Bore Diameter1 5/8 in
Mpn60BS18H X 1 5/8
Number of Chain RowsSingle
Number of Set Screws2
Number of Teeth18
Number of Teeth - Sproc.18
Outside Dia.4.685 in
Outside Dia. (In.)4.685
Outside Diameter5 in
Pitch Dia.0.75 in
Pitch Dia. (In.)0.750
Pitch Diameter4.319 in
Set Screw Dia. (In.)3/8
Set Screw Hole Dia.0.375 in
Set Screw LocationSetscrews are Placed Ov.
Setscrew LocationOne Setscrew Over The K.
SKUZO-G0028318
Sprocket Bore TypeFixed Bore
Sprocket Hub TypeType B
StandardsANSI B29.1, BIS
SubCategoryPower Transmission
Teeth Heat TreatmentHardened Teeth
Tooth Width0.459 in
TypeFinished Bore
UPC888569106155
Width Across Tooth SetsNot Applicable

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
thumbzoomZoroG002831840.651In StockTritan3.040.65 @ 1
Grainger36GE0445.51In Stock5TRITAN45.5 @ 1
thumbzoomsimsupply.comZO-G002831850.451In StockTritan50.45 @ 1
thumbzoomRaptor SuppliesAH6ULZ90.82938151In StockTRITAN90.8293815 @ 1
