Schneider LC1K09004M7

B01KZ3G8CU

NEW Schneider Contactor LC1K09004M7 LC1-K09004M7 4P 4NO 20A 220/230V AC Coil

NEW Schneider Contactor LC1K09004M7 LC1-K09004M7 4P 4NO 20A 220/230V AC Coilzoom

Attributes

Key Value
[Icw] Rated Short-Time .90 A 50 ?C - 1 s power .
[Ith] Conventional Free.20 A 50 ?C power circuit
[Uc] Control Circuit Vo.220...230 V AC 50/60 Hz
[Ue] Rated Operational .power circuit 690 V AC .
[Ui] Rated Insulation V.power circuit 600 V UL .
[Uimp] Rated Impulse Wi.8 kV
Ambient Air Temperature.-50-80 ?C
Average Impedance3 mOhm - Ith 20 A 50 Hz.
California Proposition .Antimony oxide & Antimo.
China Rohs RegulationPro-active China RoHS d.
Circularity ProfileENVEOLI1503003EN
Coil Power Rating30 VA Inrush, 4.5 VA Ho.
Coil Voltage220 to 230, 220 to 230 .
Connections - Terminalsscrew clamp terminals 1.
Contact Configuration4NO, 4 NO
Contact Current Rating20 A
Contact Rating20 A at 600 VAC
Contactor Applicationresistive load
Contactor seriesTeSys K
Contacts configurationNO x4
Control Circuit TypeAC 50/60 Hz
Control Circuit Voltage.operational 0.8...1.15 .
Control Voltage220 to 230 V
Control voltage220V AC
Depth57 mm
Device Applicationcontrol
Device Short NameLC1K
Dimensions1.17 in W x 2.24 in D x.
Enclosure TypeOpen
Environmental DisclosureENVPEP1503003EN
Eu Rohs DirectiveCompliant
Flame RetardanceV1 conforming to UL 94 .
Frequency Rating50/60, 50/60 Hz
Heat Dissipation1.3-1.3 W
Height58mm, 58 mm
Hold-In Power Consumpti.4.5-4.5 VA 20 ?C)
Inrush Power In Va30-30 VA 20 ?C)
Insulation voltage690V
Ip Degree Of ProtectionIP2x VDE 0106
Irms Rated Making Capac.110 A AC power circuit .
Leadsscrew terminals
ManufacturerSCHNEIDER ELECTRIC
Max. operating current9A
Maximum Operating Rate3600 cyc/h
Mechanical Durability10 Mcycles
Mechanical Robustnessshocks contactor closed.
Mercury FreeYes
Mountingfor DIN rail mounting,
Mounting Supportrail || plate
Mounting typeSurface
Mounting TypePanel Mount
Net Weight0.18 kg
Number of Poles4
Operating Altitude6561.68 ft (2000 m) wit.
Operating Cycles10000000, 10000000 Cycl.
Operating temperature-25...50?C
Operating Temperature-13 to 122, -13 to 122 .
Operating Time10...20 ms coil de-ener.
Overvoltage CategoryIII
Pole Contact Composition4 NO
Poles Description4P
Product CertificationsCSA || UL || UKCA
Product NameTeSys K
Product Or Component Ty.contactor
Protective TreatmentTC IEC 60068 || TC DIN .
RangeTeSys
Rated Breaking Capacity110 A 415 V IEC 60947 |.
Reach Free Of SvhcYes
Reach RegulationFree of Substances of V.
Rohs Exemption Informat.Yes
Safety Reliability LevelB10d = 1369863 cycles c.
SeriesTeSys Micra Series
StandardsBS 5424 || IEC 60947 ||.
Sustainable Offer StatusGreen Premium product
Switching capacity4kW
Terminal TypeScrew Clamp
Tightening Torque1.3 N.m screw clamp ter.
Toxic Heavy Metal FreeYes
TypeK-Line LC1K
Type of contactor4-pole
Utilisation CategoryAC-1
Warranty18 months
WeeeThe product must be dis.
Width45mm, 45 mm

All Prices

Img Seller Supplier SKU Min Price MOQ In Stock Lead Time Brand Weight Preferred Tier
TMELC1K09004M732.471In StockSCHNEIDER ELECTRIC32.47 @ 1
RS Delivers188-472843.22419Schneider Electric43.224 @ 1
thumbzoomstandardelectricsupply.com216768675.111In StockSquare D (Schneider Electric)75.11 @ 1
thumbzoommayerelectric.comSQDLC1K09004M782.21In StockSCHNEIDER ELECTRIC0.39682.2 @ 1
thumbzoommostelectric.comLC1K09004M789.071In StockSQUARE D/TELEMECANIQUE89.07 @ 1
thumbzoomRadwellLC1K09004M790.01In StockSCHNEIDER ELECTRIC TELEMECANIQUE90.0 @ 1
us.rs-online.com71414733104.811In StockSchneider Electric104.81 @ 1
Newark16B239105.581In StockSCHNEIDER ELECTRIC105.58 @ 1
